2050 transceiver - Control head and display transition PCB’s
Click here to view Control Head PCB schematic and overlay
PC-2000P03-A2 Control Head PCB Parts List
Designator Description
Barrett Part
Number
C1 Cap 15pF 5% 50V 0603 NPO NB CP-11687
C2 Cap 15pF 5% 50V 0603 NPO NB CP-11687
C3 Cap 15pF 5% 50V 0603 NPO NB CP-11687
C4 Cap 15pF 5% 50V 0603 NPO NB CP-11687
C5 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C6 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C7 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C8 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C9 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C10 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C11 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C12 Cap 1uF 5% 16V 0805 Y5V CP-11674
C13 Cap 1uF 5% 16V 0805 Y5V CP-11674
C14 Cap 1uF 5% 16V 0805 Y5V CP-11674
C15 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C16 Cap 1uF 5% 16V 0805 Y5V CP-11674
C17 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C18 Cap 1uF 5% 16V 0805 Y5V CP-11674
C19 Cap 22uF Tant 16V C or D case CP-01590
C20 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C21 Cap 1uF 5% 16V 0805 Y5V CP-11674
C22 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C23 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C24 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C25 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C26 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C27 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C28 Cap 22uF Tant 16V C or D case CP-01590
C29 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C30 Cap 100pF 5% 50V 0603 NPO NB CP-11673
C31 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C32 Cap 1uF 5% 16V 0805 Y5V CP-11674
C33 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C34 Cap 22uF Tant 16V C or D case CP-01590
C35 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C36 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C37 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C38 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C39 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C40 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C41 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C42 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C43 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C44 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C45 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
