Opening the 2040 for PCB access
Remove the battery cartridge as shown
Using an M3 hex driver remove the cap screws as shown
Grasp the front panel of the 2040 adaptor and gently pull away from the connectors
Using a flat blade screw driver remove the wires from the terminal block to the connector on the battery
cartridge housing.
