2040 Manpack adapter – Automatic antenna tuner PCB
Click here to view Automatic antenna tuner PCB schematic and overlay
PC-2040P27-A1 ATU PCB Parts List
Designator Description Barrett Part Number
C1 Cap 6p8 +/- 0.5pF 50V 0603 NPO NB CP-11694
C2 Cap 6p8 +/- 0.5pF 50V 0603 NPO NB CP-11694
C3 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C4 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C5 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C6 Cap 100nF 20% 63V 1206 NO PHILIPS CP-00916
C7 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C8 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C9 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C10 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C11 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C12 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C13 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C14 Cap 100pF 5% 500V 1206 NPO NB CP-00059
C15 Cap 100pF 5% 500V 1206 NPO NB CP-00059
C16 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C17 Cap 1nF 5% 50V 0603 NPO NB CP-11668
C18 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C19 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C21 Cap 220pF 5% 500V 1206 NPO NB CP-00062
C22 Cap 220pF 5% 500V 1206 NPO NB CP-00062
C24 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C25 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C26 Cap 10pF 5% 50V 0603 NPO NB CP-11701
C27 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C28 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
CP1 Cap Net 1nF 50V NPO 5% NB 0612 CP-11703
D2 Di HSMS2802 Schottky SMD DI-03318
D3 Di Pin 5082-2800 DI-03306
D4 Di Pin 5082-2800 DI-03306
L1 Ind 8T L1 330nH 2040 ATU IN-15037
L2 Ind 11T L2 600nH 2040 ATU IN-15038
L3 Ind 16T L3 1u09 2040 ATU IN-15039
L4 Ind 21T L4 1u99 2040 ATU IN-15040
L5 Ind 28T L5 3u62 2040 ATU IN-15041
L6 Ind 38T L6 6u59 2040 ATU IN-15042
L7 Ind 36T L7 11u99 2040 ATU IN-15043
L8 Ind 49T L8 21u83 2040 ATU IN-15044
L9 Ind 66T L9,10,11 39u73 2040 ATU IN-15045
L10 Ind 66T L9,10,11 39u73 2040 ATU IN-15045
L11 Ind 66T L9,10,11 39u73 2040 ATU IN-15045
P1 Conn IDC 14W F RA CN-24192
P2 Conn IDC 10W F RA CN-24144
P5 Plug 6 pin Polarised CN-14106
R1 Res 1k 5% 0.063W 0603 NB RE-10287
