Barrett 2040 - 2040 Manpack Adapter - Front Panel PCB

74
2040 Manpack adapter - Front Panel PCB
Click here to view Front Panel PCB schematic and overlay
PC-2040P02-A1 Front Panel PCB Parts List
Designator Description
Barrett Part
Number
C1 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C10 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C11 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C12 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C13 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C14 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C15 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C16 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C17 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C18 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C19 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C2 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C20 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C21 Cap 10uF 16v Y5V +80/-20% 1206 NB CP-11710
C22 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C23 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C24 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C25 Cap 1uF 5% 16V 0805 Y5V CP-11674
C26 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C27 Cap 22uF Tant 16V Case C CP-01590
C28 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C29 Cap 10nF 5% 50V 0603 X7R NB CP-11667
C30 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C31 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C32 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C3 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C4 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C5 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C6 Cap 100nF 5% 50V 0603 X7R NB CP-11666
C7 Cap 1uF 5% 16V 0805 Y5V CP-11674
C8 Cap 22uF Tant 25V Case C or D CP-NEW
C9 Cap 22uF Tant 16V Case C CP-01590
D1 Di BAV70 SMD DI-03316
D2 Di BAW56 SOT23 SMD DI-03300
D3 Di BAW56 SOT23 SMD DI-03300
L1 Ind 10uH 1210 IN-03600
L2 Ind 10uH 1210 IN-03600
L3 Ind 10uH 1210 IN-03600
L4 Ind 10uH 1210 IN-03600
L5 Ind 100uH 3DF TOKO IN-15025
P1
Conn Mil 15W F Panel Blk 62IN-12E-14-
15S(219)(624
CN-24172
P2
Conn Mil 6W M Panel Blk 62IN-12E-10-
6P(219)(624) CN-24174
P3 Conn Mil 6W F Panel Blk 62IN-12E-10-6S(219)(624) CN-24175
P4 Conn Mil 4W M Panel Blk 62IN-12E-8-4P(219)(624) CN-24173
