2040 Manpack adapter - Base PCB
Click here to view Base PCB schematic and overlay
PC-2040P01-A1 Base PCB Parts List
Designator Description Barrett Part Number
P1 Conn D25M ST Wire Wrap CN-24180
P2 Conn Header M 14W Dual ST CN-24190
P3 Conn Header M 40W Dual ST CN-24191
P4 Conn Pin UHF M PCB ST Custom CN-20419
Conn RF Shell UHF M PCB ST Custom CN-20424
P5 Conn Pin UHF M PCB ST Custom CN-20419
Conn RF Shell UHF M PCB ST Custom CN-20424
P7 Conn D 7W (2P/5D) F ST Cable CN-24166
Contact F 30A Cable For (2P/5D) CN-24168
