Bartell B436 - Electric Power Trowel Operation

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 16 -
CUSTOMER PARTS LIST
Assembly #
Walk-Behind Assembly
Assembly List
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 20903 20901 Base Unit 1 6/8/2004
20 20033 20068 Blade Kit, 6 x 14, Finish Imperial 1 6/8/2004
30 20520A 20562 Handle Ass’m 36 Standard 1 6/8/2004
40 Engine Engine Honda, Robin, B&S 1 6/8/2004
50 14278 14280 Stud, Combo 4 6/8/2004
60 10919 10905 Flat Washer (5/16), (3/8) 2 6/8/2004
70 10402 10402 Lock Washer (5/16), (3/8) 4 6/8/2004
80 10915 10901 Hex Nut, (5/16-18), (3/8-16) 4 6/8/2004
90 21006A 21005 Clutch, B436 3/4" Bore 1 6/8/2004
95 11254A N/A Clutch Spacer 1 6/8/2004
100 14270 14285 Sheave,(5"x3/4"Bore),(MB58x3/4”Bore) 1 6/8/2004
110 10208A 10208A Key 3/16”Sq x 1-1/2”LG 1 6/8/2004
120 11030 ¹11178 V-Belt, (A25), ¹(B29) 1 6/8/2004
130 21066 21065 Belt Guard 1 6/8/2004
140 10902 10902 Lock Washer, 3/8" Dia 1 6/8/2004
150 10901 10901 Hex Nut, 3/8-16 1 6/8/2004
160 20447A 20448A Safety Ring - Removable 1 6/8/2004
165 30019 30019 HHCS, 1/2-13 x 1 1/2"LG 4 6/8/2004
170 50026 50026 Flat Washer 1/2" 4 6/8/2004
175 11296 11296 5/8" Rubber Washer 8 6/8/2004
180 10547 10547 Nylock Nut, 1/2-13 4 6/8/2004
190 10910 10910 Stud, 3/8-16 x 1-3/4"LG 1 6/8/2004
240 20189 20189 Hoist Hook GX160, No Brake 1 6/8/2004
250 11256 11256 FHSCS 5/16-24 x 1”LG 4 6/8/2004
270 20512 20512 Carry Bar Ass’m 1 6/8/2004
Rev. 1 Belt for B446 changed, was 11047 (BP28) now 11178 (B29) 10/2005
