WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 22 -
CUSTOMER PARTS LIST
Assembly #
20921A (B436), 20928A (B446)
Gearbox Assembly
Item # B436 (B446) Description Qty Eff. Date
10 10921A 10928A Gear Housing 1 5/1/2004
20 10917A 10929A Gearbox Cover 1 1/1/1997
30 10916 10903 FHSCS, 1/4-20 x 3/4”LG (5/16-18 x 1”LG) 8 5/1/2002
40 10618A 10607A Main Shaft 1 4/7/1998
50 10616A 10605A Worm Gear RH 1 1/1/1997
60 10615 10609 Woodruff Key 1 1/1/1997
70 10614 10603 Taper Bearing, 4T-30305 (4T-30306) 1 3/1/2004
80 10617 14256 Bearing, 6205 (6207) 1 1/1/1997
90 10613 10613 Pressure Washer 2 1/1/1997
100 10601 10601 FHSCS, 3/8-16 x 1”LG 8 1/1/1997
110 10621 10610
Oil Seal, 1 1/16”ID x 1 5/8”OD x 5/16”THK, EPDM
(1 3/8”ID x 2.129”OD x 0.437”THK, EPDM)
1 1/1/1997
120 10279 10280 Wormshaft, RH 1 1/1/1997
130 10220 10229 Bearing Cone, 4T-6075 (4T-LM11949V1#BW) 1 9/16/2003
140 10224 10203 Ball Bearing, 6203 (6303C3T) 1 9/16/2003
150 10226A 10215A End Cap 1 9/16/2003
160 10227 10228 O-Ring, #224, EPDM (#227) 2 1/1/1997
170 10213 10213 SHCS, 1/4-20 x 3/4”LG,Zinc Plated 8 1/1/1997
180 10217A 10231A Flange 1 1/1/1997
190 10219 10230 Bearing Cup, 4T-6157 (4T-LM11910#BW) 1 1/1/1997
200 10214 10214 Oil Seal, 3/4”IDd x 1-1/4”OD x 3/8”THK, EPDM 1 1/1/1997
210 10930 10930 Sight Plug 1 1/1/1997
220 10931 10931 O-Ring, #213, EPDM 1 1/1/1997
230 10909 10909 Relief Valve 1 1/1/1997
240 10911 10911 Pipe Plug, 3/8 NPT 2 1/1/1997
250 10637 10637 Lock Washer C/S 3/8”Dia 1 2/07/06
