WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 20 -
CUSTOMER PARTS LIST
Assembly #
20810, 20820
Spider Plate Assembly, Greased
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 10810A 10820A Grease Spider Plate 1 1/1/1997
20 10801 10801 Grease Fitting,1/8npt x 65° 4 1/1/1997
30 10822 10822 Caplug, Grease Nipple, Red 4 1/1/1997
40 10411A 10405A Trowel Arm 4 9/5/2000
50 10806 10806 HHCS, 3/8-16 x 7/8"LG 4 1/1/1997
60 10805 10805 Lock Washer, 3/8"Dia 4 1/1/1997
70 10817A 10819A Lift Lever 4 9/12/2000
80 10808 10808 Jam Nut, 3/8-16 8 1/1/1997
90 10807 10807 Carriage Bolt, 3/8-16 x 1-1/4"LG, 4 1/1/1997
100 10809 10809 SHSS, 3/8-16 x 1"LG, CUP PT. 4 1/1/1997
110 10404 10404 Adjusting Screw, 1-1/4" LG 4 1/1/1997
Assembly #
20627, 20626
Pressure Plate Assembly
Item # Part #
(436)
Part #
(446)
Description Qty Eff. Date
10 10660P 10659P Pressure Plate 1 1/1/1997
20 10664 10663 Thrust Bearing P/P 1 1/1/1997
30 10668P 10667P Pressure Plate Cap 1 12/6/2002
