Bartell B436 - Base Unit Parts List

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 18 -
CUSTOMER PARTS LIST
Assembly #
20903, 20901
Base Unit, B436 / B446, Greased Spider
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 20810A 20820T Spider plate Ass’y 1 5/1/2004
20 20627 20626T Pressure Plate Ass’y 1 1/1/1997
30 10608A 10608A Key, 1/4”Sq x 1-5/32”LG 1 5/1/2002
40 20921A 20928AT Gearbox Ass’y 1 4/7/1998
50 10814 10804 Retainer 1 1/1/1997
60 10812 10802 SHCS (7/16-14x1-1/4”LG),(1/2-13x1-1/2”LG) 1 1/1/1997
70 10312B 10311C Yoke Arm 1 3/1/2004
80 10923 10914 Pin 1 1/1/1997
90 10922 10913 Retaining Ring, E Type 2 1/1/1997
100 10910 10910 Stud, 3/8-16 x 1-3/4"LG 4 1/1/1997
110 10902 10902 Lock Washer, 3/8" Dia, Medium 4 1/1/1997
120 10901 10901 Hex Nut, 3/8-16 4 1/1/1997
130 14274 14315B Mounting Rails (Incl LH & RH) 1 9/16/2003
140 14273 14316B Engine Mounting Plate, Metric 1 9/16/2003
150 12727 14317 SHCS (5/16-18x1-1/4"LG),(3/8-16x1-1/4”LG) 4 9/16/2003
160 10823 10823 Cap Plug EC-12 1 1/1/1997
