WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 24 -
CUSTOMER PARTS LIST
Assembly #
20520A (B436), 20562 (B446)
Handle Assembly
Item # (B436) (B446) Description Qty Eff. Date
10 20517 20564 Handle Bracket Standard 1 1/1/1997
20 10518 10505 Handle Clamp 1 1/1/1997
30 20519UC 20563UC Handle Tube 1 1/1/1997
40 10516 10503 Support Block 1 1/1/1997
50 10515 10515 Pulley 1 1/1/1997
60 10514 10514 Dowel Pin 1 1/1/1997
70 10538 10506 HHCS 3/8-16 x 2-1/4”LG (2-1/2”LG) 1 1/1/1997
80 10507 10507 HHCS 3/8-16 x 1"LG 4 1/1/1997
90 10317 10317 Nylock Nut 3/8-16 6 1/1/1997
100 20302 20301 Hand Knob Assembly 1 1/1/1997
110 10314 10314 Slide Bushing 1 1/1/1997
120 20321A 20322A Cable 1 1/1/1997
125 10901 10901 Hex Nut 3/8-16 1 1/1/1997
130 10309 10309 Pin 3/16”Dia x 1-1/2”LG 1 1/1/1997
140 10522 10510 SHCS 1/4-20 x 1/4"LG (3/8”LG) 1 1/1/1997
150 10511 10511 RHMS 1/4-20 x 3/8"LG 1 1/1/1997
160 10508 10508 Throttle Control 1 1/1/1997
170 20304 20305 Cable Assembly 1 1/1/1997
180 10703 10703 Lock Washer, #10 Dia, Internal 4 1/1/1997
190 10513 10513 RHMS #10-24 x 1/4"LG 2 1/1/1997
200 20713A 20713A Safety Switch Assembly 1 2/26/2002
210 20702 20703 Wire Assembly 1 1/1/1997
230 10509 10509 Handle Grip 1 1/1/1997
