SPECIFICATIONS
WALK-BEHIND TROWEL
Walk Behind Trowel (GASOLINE)
Blade Speed (RPM)
Engine Speed (RPM)
130-160
3600
Clutch Type
Variable Speed
Centrifugal
Yes
Gearbox Oil
Gearbox Oil Capacity
Engine Fuel
Engine Oil Alert
Cooling
Starting
Agma 8 compounded gear oil
16 oz. (473 ml), 19 oz. (562 ml)
Gasoline – Unleaded
Yes
Air
Recoil Starter - Manual
Dead-man Safety Switch
Fuel Capacity (approximately)
Running Time (approximately)
Yes
3 Gal. (12.5 L)
2 ½ hours
Number of Blades 4
Engine Acoustic Power Lwa (dB)
Engine Acoustic Pressure Lpa (Db)
Level of Vibration
Vibration value on the handle
97-103
82-86
1.1-1.5
7.0 aw
Options Oil-Bath Spider Assembly
Insta-Pitch Lever
Hoist Hook
Carry Bar
Folding Handle
• Power rating conforming to DIN 6270 & ISO 3048/1 Std.
• RPM results may vary by engine option.
Model Path
Power Source
(gas option)
Float Blade
Size
Finish
Trowel Size
Combination
Blade Size
Pans
Flaots
Pans
Flaots
Operating
Weight
B436
36"
(90 cm)
5.5 hp Honda OHV
6 hp Honda OHV
9 hp Honda OHV
4 hp Robin OHV
10” x 14"
(25 x 36 cm)
6” x 14"
(15 x 36 cm)
8” x 14"
(20 x 36 cm)
38 ½"
(98 cm)
186 lbs.
85 kg
Up to 165 lb.
(75 kg)
B446
46"
(120 cm)
9 hp Honda OHV
9 hp Robin OHV
11 hp Honda OHV
11 hp Robin OHV
10” x 18"
(25 x 46 cm)
6” x 18"
(15 x 46 cm)
8” x 18"
(20 x 46 cm)
48 ½"
(123 cm)
187 lbs.
85 kg
Up to 245 lb.
(110 kg)
