Bartell B436 - Instapitch Handle Assembly Parts List

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX 905-458-5484
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX 800-633-5534
Created: 07/04
Revised: 4/06
- 26 -
CUSTOMER PARTS LIST
Assembly #
20502 (B436), 20581 (B446)
Handle Assembly (Instapitch Option)
Item # (B436) (B446) Description Qty Eff. Date
10 20518 20564 Handle Bracket 1 1/1/1997
20 10505 10505 Handle Clamp 1 1/1/1997
30 11510 11513 Rigid Handle, Standard 1 1/1/1997
40 10503 10503 Support Block 1 1/1/1997
50 10515 10515 Cable Pulley 1 1/1/1997
60 10514 10514 Dowel Pin 1 1/1/1997
70 11583 11506 FHCS 3/8-16 x 3”LG (HHCS 2-1/2”LG) 1 1/1/1997
80 10507 10507 HHCS 3/8-16 x 1"LG, Gr5 4 1/1/1997
90 10317 10317 Nylock Nut 3/8-16 5 1/1/1997
100 14250 14250 Instapitch Adjust Lever 1 1/1/1997
110 14326 14326 Latch Disc, Instapitch 1 2/07/06
120 11539 20323A Pitch Adjust Cable 1 1/1/1997
125 10901 10901 Hex Nut 3/8-16 1 1/1/1997
130 10309 10309 Pin 3/16”Dia x 1-1/2” 1 1/1/1997
140 10522 10522 SHCS 1/4-20 x 1/4”LG Plain 1 1/1/1997
150 10511 10511 RHMS 1/4-20 x 3/8”LG, Slotted 1 1/1/1997
160 10508 10508 Throttle Control 1 1/1/1997
170 10919 10919 Flat Washer, 5/16”Dia 1 1/1/1997
180 10703 10703 Lock Washer, #10 Internal Tooth 4 1/1/1997
190 10513 10513 RHMS #10-24 x 1/4"LG 6 1/1/1997
200 20713A 20713 Safety Switch Ass’y 1 1/1/1997
210 20702 20703 Wire Assembly 1 1/1/1997
220 50062 50062 Stop Switch 1 1/1/1997
230 10509 10509 Handle Grips 2 1/1/1997
240 12469 12469 Clevis Pin 3/16”Dia x 5/8”LG 1 2/07/06
