Installation and connection
This page describes the process of mounting and connection the monitor.
Completeness check of the product(see page 78)
Electrical connection(see page 78)
Mechanical mounting(see page 79)
Connection of the additional modules(see page 80)
Completeness check of the product
Before installing the monitor, be sure to check that it is complete and all components are
available.
The monitor kit includes:
Monitor 1 pc
Wall mounting bracket 1 pc
Manual 1 pc
Set of wires with connectors for connection of alarm loops, external dynamics
and home automation
1 pc
Resistors for alarm sensors 8 pcs
Installation screws 2 pcs
Electrical connection
After verifying the device's completeness, you can switch to the monitor connection.
To connect monitor you will need:
An Ethernet UTP CAT5 or higher cable connected to a PoE switch or to a normal switch/
router.
Power supply at +12 Volts DC if there isn't PoE.
Wires must be brought for the connection of alarm loops and home automation (optional).
The connection scheme of all components is presented below:
Cablelengthrecommendations
The maximum length of the UTP CAT5 cable segment shouldnot exceed 100 meters,
according to the IEEE 802.3 standard.

