AW00097209000 Real-Time Trigger Functionality
Basler IP Fixed Box Cameras 101
7.3 Real-Time Triggering Impact on Streams
When you are setting the Streaming group parameters on the
camera, remember that because the real-time trigger operates at
the sensor level, it impacts all enabled streams. So, for example,
if you enable three streams, each image capture initiated by a
real-time trigger signal will be transmitted in all three streams.
If the Encoder Type parameter for a stream is set to "JPEG",
"MPEG4", "H.264 Base Profile" or "H.264 High Profile", the
images captured as a result of the real-time trigger will be
transmitted from the camera as part of the normal image stream
as illustrated in Figure 16 on page 98.
If the Encoder Type parameter for a stream is set to "JPEG
(triggered)" as shown to the right, the stream will only include
images captured as a result of using the real-time trigger. The
images in the stream will be motion JPEG encoded.
