AW00097209000 Technical Specifications
Basler IP Fixed Box Cameras 103
8 Technical Specifications
8.1 BIP2-640c/-dn and BIP2-1000c/-dn
Specification BIP2-640c / BIP2-640c-dn BIP2-1000c / BIP2-1000c-dn
Sensor 1/4" progressive scan color CCD
Global shutter
1/3" progressive scan color CCD
Global shutter
Effective Pixels 640 (H) x 480 (V) 1024 (H) x 768 (V)
Pixel Size 5.6 µm x 5.6 µm 4.65 µm x 4.65 µm
Frame Rate
(at full resolution)
MJPEG MPEG-4 H.264
60 fps 60 fps 95 fps
MJPEG MPEG-4 H.264
30 fps 30 fps 30 fps
Minimum Illumination
Color Mode:
Day/Night Mode:
0.10 lux, F1.0/33 ms
0.03 lux, F1.0/33 ms
0.38 lux, F1.0/33 ms
0.10 lux, F1.0/33 ms
Lens Mount CS-mount, DC Iris drive (lens not included)
Day/Night Movable IR-cut filter (BIP2-640c-dn) Movable IR-cut filter (BIP2-1000c-dn)
Image Settings Automatic gain, exposure area, backlight compensation, white balance,
electronic shutter, 180° image rotation, mirroring of images, anti-flicker,
electronic PTZ via AOI (API), text overlay, privacy masks, motion detection
Resolutions From 160 x 120 to 640 x 480 (free
scaling), 4:3, 16:9
Multiple Areas of Interest (AOIs)
From 160 x 120 to 1024 x 768 (free
scaling), 4:3, 16:9
Multiple Areas of Interest (AOIs)
Video Compression Motion JPEG: Multiple compression levels
MPEG-4: SP (Level 3)
H.264 (MPEG-4 AVC): Baseline and high profile (levels up to 5.0)
Video Streaming Multi-encoding and multi-streaming for MJPEG, MPEG-4, and H.264
VBR and CBR for MJPEG and MPEG-4
VBR, CBR, and CVBR for H.264
Uncompressed YUV images using real-time trigger (max. 4 fps)
Multicast and unicast
Table 4: BIP2-640c/-dn and BIP2-1000c/-dn Technical Specifications
