Technical Specifications AW00097209000
104 Basler IP Fixed Box Cameras
Alarm Management Ring buffer for pre and post alarm images
MicroSDHC card slot for local storage (MicroSDHC card is not included with the
camera)
Events triggered by motion detection or external input
Image upload via FTP, Email, or HTTP
Real-time Trigger Yes Yes
Protocols TCP/IP, HTTP, FTP, UDP, ICMP, ARP, DHCP, NTP,
RTP, RTSP, RTCP, SMTP, SNMP, IGMP, ZEROCONF, QoS Layer 3
Processor / Memory Multimedia video processor, FPGA, 256 MB RAM, 64 MB flash
Minimum PC
Requirements
Processor: 2.4 GHz (dual core) or 3.5 GHz (single core)
RAM: 2 GB
Graphics: Nvidia/ATi graphics card, 256 MB video RAM (more recommended),
600 MHz core clock
OS: XP, Vista, Windows 7, or Linux
NIC: 100 Mbps Ethernet
CD ROM drive
Browser: Internet Explorer 8.0 or higher
Card Slot Slot for a microSDHC card (microSDHC card is not included with the camera)
Power PoE (Power over Ethernet IEEE 802.3af
Class 2) or
+12 to +24 VDC (± 10%)
Power consumption is 3.3 W max. at 12 VDC
PoE (Power over Ethernet IEEE 802.3af
Class 2) or
+12 to +24 VDC (± 10%)
Power consumption is 3 W max. at 12 VDC
Connectors RJ-45 screw connector for 10/100 Base-T Ethernet, full or half duplex
8-pin terminal for DC power, digital I/O, and RS-485
Operating Conditions -10 °C to 50 °C (14 °F to 122 °F)
Starting temperature: 0 °C to 50 °C (32 °F to 122 °F)
< 90% relative humidity (non-condensing)
Standards DIN EN 50130-4, FCC Class A, CE,
RoHS, ONVIF
DIN EN 50130-4, FCC Class B, CE,
RoHS, ONVIF
Housing 109.7 mm x 29 mm x 44 mm, full metal casing
Weight ~ 210 g
Specification BIP2-640c / BIP2-640c-dn BIP2-1000c / BIP2-1000c-dn
Table 4: BIP2-640c/-dn and BIP2-1000c/-dn Technical Specifications
