Technical Specifications AW00097209000
110 Basler IP Fixed Box Cameras
8.5 Stress Test Results
Basler IP Cameras were submitted to an independent mechanical testing laboratory and subjected
to the stress tests listed below. After mechanical testing, the cameras produced normal images
during standard operational testing.
Test Standard Conditions
Vibration
(sinusoidal, each axis)
DIN EN 60068-2-6 10-58 Hz / 1.5 mm_58-500 Hz / 20 g_1 octave/minute
10 repetitions
Shock
(each axis)
DIN EN 60068-2-27 20 g / 11 ms / 10 shocks positive
20 g / 11 ms / 10 shocks negative
Bump
(each axis)
DIN EN 60068-2-29 20 g / 11 ms / 100 shocks positive
20 g / 11 ms / 100 shocks negative
Vibration
(broad-band random,
digital control, each axis)
DIN EN 60068-2-64 15-500 Hz / 0.05 PSD
(ESS standard profile) / 00:30 h
Table 7: Mechanical Stress Tests
