AW00097209000 Configuring the Camera
Basler IP Fixed Box Cameras 11
3. A Camera Configuration menu will open on the left side of the client as shown below. Notice
that the parameters used to configure the camera appear in groups such as the Image Controls
group and the Streaming group.
You can open a parameter group by clicking the + sign beside the group name.
By default, the camera is set so that video stream 0 is an MJPEG stream, and a Live Stream 0
tab will appear in the client as shown below. A live video stream will appear in the tab.
If more than one video stream is enabled, there will be an additional Live Stream tab available
for each enabled stream.
Depending on the type of web browser you are using and depending on how you set the stream
settings, some or all of the following buttons and boxes will appear below the live stream:
Stop - Click the Stop button to stop live image streaming. (A Start button will appear, which will
let you restart the live stream.)
Snapshot - Click the Snapshot button to capture a single image within a new browser window.
Refresh Rate - The Refresh Rate box displays the rate at which the images displayed in the
web client are refreshed. Use the button to change the refresh rate.
Note that changing the Refresh Rate setting will not change the rate at which the camera
captures or streams images. The Refresh Rate setting only affects the rate at which images are
displayed in the web client in your browser. Some browsers perform poorly when set to a high
