1-6 DECS-100 General Information 9287500991 Rev K
Range: 0 to 99 MVA, MW, Mvar
Power (Apparent, Real, and Reactive)
Accuracy: ±3.0% (at 25°C)
Range: –1.0 to –0.6, +0.6 to +1.0
Power Factor
Accuracy: ±0.02 at rated current (25°C), CT input ≥10% nominal rating
Range: 0 to 360 degrees
Phase Angle
Accuracy: ±2.0 degrees (at 25°C), CT input ≥10% nominal rating
Environment
DECS-100: –40 to 70°C (–40 to 158°F)
Operating Temperature
DECS-100: –40 to 85°C (–40 to 185°F)
Storage Temperature
CD-ROM: 0 to 50°C (32 to 122°F)
Type Tests
Shock: Withstands 20 G in three perpendicular planes
Vibration: Withstands 1.2 G at 5 to 26 Hz
Withstands 0.914 mm (0.036 in) double amplitude at 27 to 52 Hz
Withstands 5 G at 53 to 500 Hz
Salt Fog: Qualified per MIL-STD-810E
Physical
Unit: 1.10 kg (2.42 lb)
Weight
Shipping: 1.31 kg (2.88 lb)
Single Unit: 299 x 79 x 146 mm (11.75 x 3.125 x 5.75 in)
Shipping Carton Dimensions (W x H x D)
48 Units: 841 x 653 x 352 mm (33.13 x 25.69 x 13.88 in)
Agency Recognition
cURus recognition per UL Standard 508 and CSA Standard C22.2 No. 14
Complies with Det Norske Veritas Standard for Certification 2.4
CE Compliance
Emissions: CISPR11/EN55011, Level A
Electrostatic Discharge (ESD): IEC 1000-4-2/EN 61000-4-2, Level B
Radiated Susceptibility: IEC 1000-4-3/EN 61000-4-3, Level A
Electrical Fast Transient: IEC 1000-4-4/EN 61000-4-4, Level B
Radio Frequency–Conducted: IEC 1000-4-6/EN 61000-4-6, Level A
Power Frequency–Magnetic: IEC 1000-4-8/EN 61000-4-8, Level A
Dielectric: IEC 255
Surge Immunity: IEC 1000-4-5/EN 61000-4-5, Level B
Voltage Dips, Interruptions,
and Variations Immunity: IEC 1000-4-11/EN 61000-4-11, Level C
