Basler DECS-250 - Page 244

28-16 9440300990
Modbus
®
Communication DECS-250
Group
Name
Register
Type
Bytes
R/W
Range
DECS Control
FVR Active
40913 bit 7
Uint16
2
R
True=1 False=0
DECS Control
FCR Active
40913 bit 8
Uint16
2
R
True=1 False=0
DECS Control
Manual Active
40913 bit 9
Uint16
2
R
True=1 False=0
DECS PSS Meter
PSS Active
40913 bit 10
Uint16
2
R
True=1 False=0
DECS Regulator Meter
Setpoint at Lower Limit
40913 bit 11
Uint16
2
R
True=1 False=0
DECS Regulator Meter
Setpoint at Upper Limit
40913 bit 12
Uint16
2
R
True=1 False=0
Exciter Diode Monitor
Trip Open or Shorted Diode
40913 bit 13
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 1
40913 bit 14
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 2
40913 bit 15
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 3
40914 bit 0
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 4
40914 bit 1
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 5
40914 bit 2
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 6
40914 bit 3
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 7
40914 bit 4
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 8
40914 bit 5
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 9
40914 bit 6
Uint16
2
R
True=1 False=0
Contact Expansion Module
Input 10
40914 bit 7
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 1
40914 bit 8
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 2
40914 bit 9
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 3
40914 bit 10
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 4
40914 bit 11
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 5
40914 bit 12
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 6
40914 bit 13
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 7
40914 bit 14
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 8
40914 bit 15
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 9
40915 bit 0
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 10
40915 bit 1
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 11
40915 bit 2
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 12
40915 bit 3
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 13
40915 bit 4
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 14
40915 bit 5
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 15
40915 bit 6
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 16
40915 bit 7
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 17
40915 bit 8
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 18
40915 bit 9
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 19
40915 bit 10
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 20
40915 bit 11
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 21
40915 bit 12
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 22
40915 bit 13
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 23
40915 bit 14
Uint16
2
R
True=1 False=0
Contact Expansion Module
Output 24
40915 bit 15
Uint16
2
R
True=1 False=0
Network Load Share
Network Load Share Disable
40916 bit 0
Uint16
2
R
True=1 False=0
Alarms
Invalid Logic Alarm
40916 bit 1
Uint16
2
R
True=1 False=0
24
Block
40916 bit 2
Uint16
2
R
True=1 False=0
24
Pickup
40916 bit 3
Uint16
2
R
True=1 False=0
24
Trip
40916 bit 4
Uint16
2
R
True=1 False=0
24
Reserved
40916 bit 5
Uint16
2
R
True=1 False=0
DECS Control
Transient Boost Active
40916 bit 6
Uint16
2
R
True=1 False=0
AEM Configuration
AEM Communication Failure
40916 bit 7
Uint16
2
R
True=1 False=0
AEM Configuration
Duplicate AEM
40916 bit 8
Uint16
2
R
True=1 False=0
AEM Configuration
AEM Input 1 Out of Range
40916 bit 9
Uint16
2
R
True=1 False=0
