Basler DECS-250 - Page 248

28-20 9440300990
Modbus
®
Communication DECS-250
Group
Name
Register
Type
Bytes
R/W
Range
Thermocouple Protection 1
Threshold 4 Pickup
40926 bit 3
Uint16
2
R
True=1 False=0
Thermocouple Protection 1
Threshold 4 Trip
40926 bit 4
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 1 Pickup
40926 bit 5
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 1 Trip
40926 bit 6
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 2 Pickup
40926 bit 7
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 2 Trip
40926 bit 8
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 3 Pickup
40926 bit 9
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 3 Trip
40926 bit 10
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 4 Pickup
40926 bit 11
Uint16
2
R
True=1 False=0
Thermocouple Protection 2
Threshold 4 Trip
40926 bit 12
Uint16
2
R
True=1 False=0
Network Load Share
NLS Active
40926 bit 13
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 1
40926 bit 14
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 2
40926 bit 15
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 3
40927 bit 0
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 4
40927 bit 1
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 5
40927 bit 2
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 6
40927 bit 3
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 7
40927 bit 4
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 8
40927 bit 5
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 9
40927 bit 6
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 10
40927 bit 7
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 11
40927 bit 8
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 12
40927 bit 9
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 13
40927 bit 10
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 14
40927 bit 11
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 15
40927 bit 12
Uint16
2
R
True=1 False=0
Network Load Share
Receiving ID 16
40927 bit 13
Uint16
2
R
True=1 False=0
Network Load Share
NLS Configuration Mismatch
40927 bit 14
Uint16
2
R
True=1 False=0
Network Load Share
NLS ID Missing
40927 bit 15
Uint16
2
R
True=1 False=0
Network Load Share
ID 1 Enabled
40928 bit 0
Uint16
2
R
True=1 False=0
Network Load Share
ID 2 Enabled
40928 bit 1
Uint16
2
R
True=1 False=0
Network Load Share
ID 3 Enabled
40928 bit 2
Uint16
2
R
True=1 False=0
Network Load Share
ID 4 Enabled
40928 bit 3
Uint16
2
R
True=1 False=0
Network Load Share
ID 5 Enabled
40928 bit 4
Uint16
2
R
True=1 False=0
Network Load Share
ID 6 Enabled
40928 bit 5
Uint16
2
R
True=1 False=0
Network Load Share
ID 7 Enabled
40928 bit 6
Uint16
2
R
True=1 False=0
Network Load Share
ID 8 Enabled
40928 bit 7
Uint16
2
R
True=1 False=0
Network Load Share
ID 9 Enabled
40928 bit 8
Uint16
2
R
True=1 False=0
Network Load Share
ID 10 Enabled
40928 bit 9
Uint16
2
R
True=1 False=0
Network Load Share
ID 11 Enabled
40928 bit 10
Uint16
2
R
True=1 False=0
Network Load Share
ID 12 Enabled
40928 bit 11
Uint16
2
R
True=1 False=0
Network Load Share
ID 13 Enabled
40928 bit 12
Uint16
2
R
True=1 False=0
Network Load Share
ID 14 Enabled
40928 bit 13
Uint16
2
R
True=1 False=0
Network Load Share
ID 15 Enabled
40928 bit 14
Uint16
2
R
True=1 False=0
Network Load Share
ID 16 Enabled
40928 bit 15
Uint16
2
R
True=1 False=0
Network Load Share
NLS Status 1
40929 bit 0
Uint16
2
R
True=1 False=0
Network Load Share
NLS Status 2
40929 bit 1
Uint16
2
R
True=1 False=0
Network Load Share
NLS Status 3
40929 bit 2
Uint16
2
R
True=1 False=0
Network Load Share
NLS Status 4
40929 bit 3
Uint16
2
R
True=1 False=0
Reserved
40929 bit 4
Reserved
40929 bit 5
