DECS-250 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Range
Reserved
40929 bit 6
Grid Code Parameters
LFSM Enable
40929 bit 7
Uint16
2
R
True=1 False=0
Grid Code Parameters
LFSM Active
40929 bit 8
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Enable
40929 bit 9
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Active
40929 bit 10
Uint16
2
R
True=1 False=0
Grid Code Parameters
Grid Code Enabled
40929 bit 11
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Enable
40929 bit 12
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Disconnect Timing
40929 bit 13
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Disconnect Timed Out
40929 bit 14
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Remote Communications Active
40929 bit 15
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Active
40930 bit 0
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Remote Communications Fail
40930 bit 1
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Remote Communications Fail
40930 bit 2
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Output Limit
40930 bit 3
Uint16
2
R
True=1 False=0
Grid Code Parameters
LFSM Recovery Active
40930 bit 4
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Disabled
40930 bit 5
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Continuous Operation
40930 bit 6
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Frequency Low Timing
40930 bit 7
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Frequency High Timing
40930 bit 8
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Voltage Low Timing
40930 bit 9
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Voltage High Timing
40930 bit 10
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Out of Range Timing
40930 bit 11
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Disconnected
40930 bit 12
Uint16
2
R
True=1 False=0
Grid Code Parameters
GCC Reconnect Timing
40930 bit 13
Uint16
2
R
True=1 False=0
Grid Code Parameters
LFSM O Active
40930 bit 14
Uint16
2
R
True=1 False=0
Grid Code Parameters
LFSM U Active
40930 bit 15
Uint16
2
R
True=1 False=0
Grid Code Parameters
LFSM Normal Operation
40931 bit 0
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Modbus Communications Fail
40931 bit 1
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT CAN Bus Communications Fail
40931 bit 2
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT AEM Comm Fail
40931 bit 3
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Modbus Communications Fail
40931 bit 4
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC CAN Bus Communications Fail
40931 bit 5
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC AEM Comm Fail
40931 bit 6
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Remote Communications Active
40931 bit 7
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Bridge Enable
40931 bit 8
Uint16
2
R
True=1 False=0
Grid Code Parameters
APC Bridge Active
40931 bit 9
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Bridge Enable
40931 bit 10
Uint16
2
R
True=1 False=0
Grid Code Parameters
LVRT Bridge Active
40931 bit 11
Uint16
2
R
True=1 False=0
Grid Code Parameters
kW Threshold Status
40931 bit 12
Uint16
2
R
True=1 False=0
Metering
Table 28-8. Metering Group Parameters
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Field Voltage Meter
V
X
41000
Float
4
R
Volt
-1000 – 1000
Field Current Meter
I
X
41002
Float
4
R
Amp
0–2000000000
DECS PSS Meter
Terminal Frequency Deviation
41004
Float
4
R
Percent
n/a
DECS PSS Meter
Compensated Frequency
Deviation
41006
Float
4
R
Percent
n/a
DECS PSS Meter
PSS output
41008
Float
4
R
n/a
n/a
DECS Regulator Meter
Tracking error
41010
Float
4
R
Percent
n/a
DECS Regulator Meter
Control output PU
41012
Float
4
R
Per Unit
-10 – 10
