Basler DECS-250 - Page 253

9440300990 28-25
DECS-250 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Per Unit Meter
Ia Pickup
41424
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Ib Pickup
41426
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Ic Pickup
41428
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
I Average Pickup
41430
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
kW Pickup
41432
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
kVA Pickup
41434
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Kvar Pickup
41436
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Positive Sequence Voltage
Pickup
41438
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Negative Sequence Voltage
Pickup
41440
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Positive Sequence Current
Pickup
41442
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Negative Sequence Current
Pickup
41444
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vab Pickup
41446
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vbc Pickup
41448
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Vca Pickup
41450
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus V Average Pickup
41452
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Voltage Difference Pickup
41454
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Power in Voltage Pickup
41456
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Generator Frequency Pickup
41458
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Bus Frequency Pickup
41460
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Ifd Pickup
41462
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Vfd Pickup
41464
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Slip Frequency Pickup
41466
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Icc Pickup
41468
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
AVR Setpoint Pickup
41470
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
FCR Setpoint Pickup
41472
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
FVR Setpoint Pickup
41474
Float
4
R
Per Unit
-10 – 10
Per Unit Meter
Var Setpoint Pickup
41476
Float
4
R
Per Unit
-10 – 10
Power Meter
Scaled PF
41478
Float
4
R
Power
Factor
-1 – 1
AEM Metering
Analog Input 1 Raw Value
41480
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 2 Raw Value
41482
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 3 Raw Value
41484
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 4 Raw Value
41486
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 5 Raw Value
41488
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 6 Raw Value
41490
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 7 Raw Value
41492
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 8 Raw Value
41494
Float
4
R
Milliamp
n/a
AEM Metering
Analog Input 1 Scaled Value
41496
Float
4
R
n/a
n/a
AEM Metering
Analog Input 2 Scaled Value
41498
Float
4
R
n/a
n/a
AEM Metering
Analog Input 3 Scaled Value
41500
Float
4
R
n/a
n/a
AEM Metering
Analog Input 4 Scaled Value
41502
Float
4
R
n/a
n/a
AEM Metering
Analog Input 5 Scaled Value
41504
Float
4
R
n/a
n/a
AEM Metering
Analog Input 6 Scaled Value
41506
Float
4
R
n/a
n/a
AEM Metering
Analog Input 7 Scaled Value
41508
Float
4
R
n/a
n/a
AEM Metering
Analog Input 8 Scaled Value
41510
Float
4
R
n/a
n/a
AEM Metering
Thermocouple 1 Raw Value
41512
Float
4
R
Millivolt
n/a
AEM Metering
Thermocouple 2 Raw Value
41514
Float
4
R
Millivolt
n/a
AEM Metering
Analog Output 1 Raw Value
41516
Float
4
R
n/a
n/a
AEM Metering
Analog Output 2 Raw Value
41518
Float
4
R
n/a
n/a
