Modbus
®
Communication DECS-250
Group
Name
Register
Type
Bytes
R/W
Unit
Range
AEM Metering
Analog Output 3 Raw Value
41520
Float
4
R
n/a
n/a
AEM Metering
Analog Output 4 Raw Value
41522
Float
4
R
n/a
n/a
AEM Metering
Analog Output 1 Scaled Value
41524
Float
4
R
n/a
n/a
AEM Metering
Analog Output 2 Scaled Value
41526
Float
4
R
n/a
n/a
AEM Metering
Analog Output 3 Scaled Value
41528
Float
4
R
n/a
n/a
AEM Metering
Analog Output 4 Scaled Value
41530
Float
4
R
n/a
n/a
AEM Metering
Thermocouple Input 1 Scaled
Value
41532
Float
4
R
Deg F
n/a
AEM Metering
Thermocouple Input 2 Scaled
Value
41534
Float
4
R
Deg F
n/a
Reserved
41536-51
Grid Code
Q Reference
41552
Float
4
R
Per Unit
-10 – 10
Grid Code
P Reference
41554
Float
4
R
Per Unit
-10 – 10
Grid Code
State
41556
Uint32
4
R
n/a
Inactive=0
Active=1
Grid Code
Grid Connect State
41558
Uint32
4
R
n/a
Disabled=0
Continuous
Operation=1
Low Frequency
Timing=2
High Frequency
Timing=3
Low Voltage
Timing=4
High Voltage
Timing=5
Out of Range
Timing=6
Disconnected=7
Reconnect
Timing=8
Grid Code
Grid Disconnect Flag
41560
Int32
4
R
n/a
n/a
Grid Code
LVRT Mode
41562
Uint32
4
R
n/a
Disabled=0
Q(PF)=1
Q(Voltage
Limit)=2
Q(U)=3
Q(P)=4
Q(Third Party)=5
Freeze Output=6
Grid Code
LFSM Mode
41564
Uint32
4
R
n/a
Initialize=0
Nominal=1
Underfrequency=2
Overfrequency=3
Recovery=4
Grid Code
Remote LVRT Status
41566
Uint32
4
R
n/a
Disabled=0
Active=1
Failed=2
Grid Code
Remote LFSM Status
41568
Uint32
4
R
n/a
Disabled=0
Active=1
Failed=2
Grid Code
PF Mode Reference
41570
Float
4
R
n/a
n/a
Grid Code
Q U Mode Reference
41572
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Voltage Limit Mode Reference
41574
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Third Party Mode Reference
41576
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Reference
41578
Float
4
R
Per Unit
-10 – 10
Grid Code
LVRT Modbus Comm Fail Timer
41580
Float
4
R
Second
0–600
Grid Code
LVRT CAN Bus Comm Fail Timer
41582
Float
4
R
Second
0–600
Grid Code
APC Modbus Comm Fail Timer
41584
Float
4
R
Second
0–600
Grid Code
APC CAN Bus Comm Fail Timer
41586
Float
4
R
Second
0–600
Grid Code
APC Integrator State
41588
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Error
41590
Float
4
R
Per Unit
-10 – 10
Grid Code
APC P Desired
41592
Float
4
R
Per Unit
-10 – 10
