Basler DECS-250 - Page 255

9440300990 28-27
DECS-250 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Grid Code
APC Bias Voltage
41594
Float
4
R
n/a
n/a
Grid Code
LVRT Q Desired
41596
Float
4
R
Per Unit
-10 – 10
Grid Code
LVRT Bias Voltage
41598
Float
4
R
n/a
n/a
Grid Code
Test Signal
41600
Float
4
R
n/a
n/a
Grid Code
Active Power Adjust CAN Bus
41602
Float
4
R
Per Unit
-10 – 10
Grid Code
PF Reference Adjust CAN Bus
41604
Float
4
R
n/a
n/a
Grid Code
Q Voltage Limit Adjust CAN Bus
41606
Float
4
R
Per Unit
-10 – 10
Grid Code
Q U Voltage Bus for Zero Q
Adjust CAN Bus
41608
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Third Party Adjust CAN Bus
41610
Float
4
R
Per Unit
-10 – 10
Grid Code
Active Power Adjust Modbus
41612
Float
4
R
Per Unit
-10 – 10
Grid Code
PF Reference Adjust Modbus
41614
Float
4
R
n/a
n/a
Grid Code
Q Voltage Limit Adjust Modbus
41616
Float
4
R
Per Unit
-10 – 10
Grid Code
Q U Voltage Bus for Zero Q
Adjust Modbus
41618
Float
4
R
Per Unit
-10 – 10
Grid Code
Q Third Party Adjust Modbus
41620
Float
4
R
Per Unit
-10 – 10
Grid Code
APC Mode
41622
Uint32
4
R
n/a
Inactive=0
Active=1
LFSM Override=2
Grid Code
Grid Connect Voltage Timer
41624
Float
4
R
Second
0–2000
Grid Code
Grid Connect Frequency Timer
41626
Float
4
R
Second
0–2000
Grid Code
Grid Connect Disconnect Timer
41628
Float
4
R
Second
0–2000
Grid Code
Grid Connect Reconnect Timer
41630
Float
4
R
Second
0–2000
Limiters
Table 28-9. Limiter Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
OEL Primary Current Hi
41700
Float
4
R W
Amp
0–40
OEL Primary Current Mid
41702
Float
4
R W
Amp
0–30
OEL Primary Current Lo
41704
Float
4
R W
Amp
0–20
OEL Primary Time Hi
41706
Float
4
R W
Second
0–10
OEL Primary Time Mid
41708
Float
4
R W
Second
0–120
OEL Primary Current Hi Off
41710
Float
4
R W
Amp
0–40
OEL Primary Current Lo Off
41712
Float
4
R W
Amp
0–20
OEL Primary Current Time Off
41714
Float
4
R W
Second
0–10
OEL Primary Takeover Current Max Off
41716
Float
4
R W
Amp
0–40
OEL Primary Takeover Current Min Off
41718
Float
4
R W
Amp
0–20
OEL Primary Takeover Time Dial Off
41720
Float
4
R W
n/a
0.1–20
OEL Primary Takeover Current Max On
41722
Float
4
R W
Amp
0–40
OEL Primary Takeover Current Min On
41724
Float
4
R W
Amp
0–20
OEL Primary Takeover Time Dial On
41726
Float
4
R W
n/a
0.1–20
OEL Primary Dvdt Enable
41728
Uint32
4
R W
n/a
Disabled=0 Enabled=1
OEL Primary Dvdt Ref
41730
Float
4
R W
n/a
-10 – 0
OEL Secondary Current Hi
41732
Float
4
R W
Amp
0–40
OEL Secondary Current Mid
41734
Float
4
R W
Amp
0–30
OEL Secondary Current Lo
41736
Float
4
R W
Amp
0–20
OEL Secondary Time Hi
41738
Float
4
R W
Second
0–10
OEL Secondary Time Mid
41740
Float
4
R W
Second
0–120
OEL Secondary Current Hi Off
41742
Float
4
R W
Amp
0–40
OEL Secondary Current Lo Off
41744
Float
4
R W
Amp
0–20
OEL Secondary Current Time Off
41746
Float
4
R W
Second
0–10
OEL Secondary Takeover Current Max Off
41748
Float
4
R W
Amp
0–40
