Basler DECS-250 - Page 256

28-28 9440300990
Modbus
®
Communication DECS-250
Name
Register
Type
Bytes
R/W
Unit
Range
OEL Secondary Takeover Current Min Off
41750
Float
4
R W
Amp
0–20
OEL Secondary Takeover Time Dial Off
41752
Float
4
R W
n/a
0.1–20
OEL Secondary Takeover Current Max On
41754
Float
4
R W
Amp
0–40
OEL Secondary Takeover Current Min On
41756
Float
4
R W
Amp
0–20
OEL Secondary Takeover Time Dial On
41758
Float
4
R W
n/a
0.1–20
OEL Scale Enable
41760
Uint32
4
R W
n/a
Disabled=0
Auxiliary Input=1
AEM RTD 1=2
AEM RTD 2=3
AEM RTD 3=4
AEM RTD 4=5
AEM RTD 5=6
AEM RTD 6=7
AEM RTD 7=8
AEM RTD 8=9
OEL Scale Takeover Signal 1
41762
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Takeover Signal 2
41764
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Takeover Signal 3
41766
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Takeover Scale 1
41768
Float
4
R W
Percent
0–200
OEL Scale Takeover Scale 2
41770
Float
4
R W
Percent
0–200
OEL Scale Takeover Scale 3
41772
Float
4
R W
Percent
0–200
OEL Scale Summing Signal 1
41774
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Summing Signal 2
41776
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Summing Signal 3
41778
Float
4
R W
Limiter
Scale
Volt
or Deg F
Adjustment range is determined by
register 41760.
-10 – 10 V when 41760 = 1
-58 – 482°F when 41760 = 2-8
OEL Scale Summing Scale 1
41780
Float
4
R W
Percent
0–200
OEL Scale Summing Scale 2
41782
Float
4
R W
Percent
0–200
OEL Scale Summing Scale 3
41784
Float
4
R W
Percent
0–200
UEL Primary Curve X1
41786
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Primary Curve X2
41788
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Primary Curve X3
41790
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Primary Curve X4
41792
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Primary Curve X5
41794
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Primary Curve Y1
41796
Float
4
R W
kilovar
0–1.5 • Rated kVA
UEL Primary Curve Y2
41798
Float
4
R W
kilovar
0–1.5 • Rated kVA
UEL Primary Curve Y3
41800
Float
4
R W
kilovar
0–1.5 • Rated kVA
UEL Primary Curve Y4
41802
Float
4
R W
kilovar
0–1.5 • Rated kVA
UEL Primary Curve Y5
41804
Float
4
R W
kilovar
0–1.5 • Rated kVA
UEL Primary Power Filter TC
41806
Float
4
R W
Second
0–20
UEL Primary Voltage Dependent Exponent
41808
Float
4
R W
n/a
0–2
UEL Secondary Curve X1
41810
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Secondary Curve X2
41812
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Secondary Curve X3
41814
Float
4
R W
kilowatt
0–1.5 • Rated kVA
UEL Secondary Curve X4
41816
Float
4
R W
kilowatt
0–1.5 • Rated kVA
