Basler DECS-250 - Page 261

9440300990 28-33
DECS-250 Modbus
®
Communication
Group
Name
Register
Type
Bytes
R/W
Unit
Range
Synchronizer
Angle Compensation
42490
Float
4
R W
Degree
0–359.9
System Configuration
Operating Mode
42492
Int32
4
R W
n/a
Generator=0
Motor=1
Reserved
42494
Network Load Share
Ki Gain
42496
Float
4
R W
No Unit
0–1000
Network Load Share
Max Vc
42498
Float
4
R W
No Unit
0–1
Reserved
42500
Relay Settings
Table 28-12. Relay Settings Group Parameters
Group
Name
Register
Type
Bytes
R/W
Unit
Range
System
Configuration
Nominal Frequency
42600
Uint32
4
R W
n/a
50 Hz=50 60 Hz=60
System
Configuration
DECS Auxiliary Summing Mode
42602
Uint32
4
R W
n/a
Voltage=0 Var=1
System
Configuration
DECS Auxiliary Input Mode
42604
Uint32
4
R W
n/a
Voltage=0 Current=1
System
Configuration
DECS Auxiliary Input Function
42606
Uint32
4
R W
n/a
DECS Input=0
PSS Test Input=1
Limiter Selection=2
Grid Code Input=3
System
Configuration
DECS Auxiliary Voltage Gain
42608
Float
4
R W
n/a
-99 – 99
System
Configuration
DECS Auto Track Time Delay
42610
Float
4
R W
Second
0–8
System
Configuration
DECS Auto Track Traverse Rate
42612
Float
4
R W
Second
1–80
System
Configuration
DECS Null Balance Level
42614
Float
4
R W
Percent
0–9999
System
Configuration
DECS Auto Trans Time Delay
42616
Float
4
R W
Second
0–8
System
Configuration
DECS Auto Trans Traverse Rate
42618
Float
4
R W
Second
1–80
Gen Volt
Configuration
Ratio Primary
42620
Float
4
R W
n/a
1–500000
Gen Volt
Configuration
Ratio Secondary
42622
Float
4
R W
n/a
1–600
Gen Volt
Configuration
Rated Primary LL
42624
Float
4
R W
Volt
1–500000
Bus Volt
Configuration
Ratio Primary
42626
Float
4
R W
n/a
1–500000
Bus Volt
Configuration
Ratio Secondary
42628
Float
4
R W
n/a
1–600
Bus Volt
Configuration
Rated Primary LL
42630
Float
4
R W
Volt
1–500000
Gen Current
Configuration
Ratio Primary
42632
Float
4
R W
n/a
1–99999
Gen Current
Configuration
Ratio Secondary
42634
Int32
4
R W
n/a
1=1 5=5
Gen Current
Configuration
Rated Primary
42636
Float
4
R
Amp
0–180000
DECS Control
Start Stop Request
42638
Uint32
4
R W
n/a
Stop=0 =1 Start =2
DECS Control
System Option Underfrequency Hz
42640
Float
4
R W
Hertz
10–75
DECS Control
System Input COM Port Manual Enabled
42642
Uint32
4
R W
n/a
Manual=1 Automatic=2
DECS Control
System Input COM Port PF var Enabled
42644
Uint32
4
R W
n/a
Off=0 PF=1 Var=2
DECS Control
System Input COM Port External Tracking
Enabled
42646
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Input COM Port Pre-position
Enabled
42648
Uint32
4
R W
n/a
NOT SET=0 SET=1
