Basler DECS-250 - Page 262

28-34 9440300990
Modbus
®
Communication DECS-250
Group
Name
Register
Type
Bytes
R/W
Unit
Range
DECS Control
System Input COM Port Pre-position
Enabled 2
42650
Uint32
4
R W
n/a
NOT SET=0 SET=1
DECS Control
System Input COM Port Raise Enabled
42652
Uint32
4
R W
n/a
NOT SET=0 Raise=1
DECS Control
System Input COM Port Lower Enabled
42654
Uint32
4
R W
n/a
NOT SET=0 Lower=1
DECS Control
System Option Input Voltage Match
Enabled
42656
Uint32
4
R W
n/a
Disabled=0 Enabled=1
DECS Control
System Option Underfrequency Mode
42658
Uint32
4
R W
n/a
UF Limiter=0
V/Hz Limiter=1
DECS Control
System Option Limiter Mode
42660
Uint32
4
R W
n/a
Off=0 UEL=1 OEL=2 UEL &
OEL=3 SCL=4 UEL &
SCL=5 OEL & SCL=6 UEL
& OEL & SCL=7
DECS Control
System Option Voltage Match Band
42662
Float
4
R W
Percent
0–20
DECS Control
System Option Voltage Match Reference
42664
Float
4
R W
Percent
0–700
DECS Control
System Option Underfrequency Slope
42666
Float
4
R W
n/a
0–3
DECS Control
Startup Primary Soft-start Bias
42668
Float
4
R W
Percent
0–90
DECS Control
Startup Primary Soft-start Time
42670
Float
4
R W
Second
1–7200
DECS Control
Startup Secondary Soft-start Bias
42672
Float
4
R W
Percent
0–90
DECS Control
Startup Secondary Soft-start Time
42674
Float
4
R W
Second
1–7200
DECS Control
System Option PF to Droop kW Threshold
42676
Float
4
R W
Percent
0–30
Protection Settings
Table 28-13. Protection Settings Group Parameters
Group
Name
Register
Type
Sz
R/W
Unit
Range
Field Overvoltage
Primary Mode
43100
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overvoltage
Primary Pickup
43102
Float
4
R W
V
Disabled=0, 1–325
Field Overvoltage
Primary Time Delay
43104
Float
4
R W
ms
Instantaneous=0, 200–30000
Field Overvoltage
Secondary Mode
43106
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overvoltage
Secondary Pickup
43108
Float
4
R W
V
Disabled=0, 1–325
Field Overvoltage
Secondary Time Delay
43110
Float
4
R W
ms
Instantaneous=0, 200–30000
Field Overcurrent
Primary Mode
43112
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overcurrent
Primary Pickup
43114
Float
4
R W
Amp
Disabled=0, 0–22
Field Overcurrent
Primary Time Delay
43116
Float
4
R W
ms
Instantaneous=0, 5000–60000
Field Overcurrent
Secondary Mode
43118
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Field Overcurrent
Secondary Pickup
43120
Float
4
R W
Amp
Disabled=0, 0–22
Field Overcurrent
Secondary Time Delay
43122
Float
4
R W
ms
Instantaneous=0, 5000–60000
Exciter Diode
Monitor
Exciter Open Diode Enable
43124
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Exciter Diode
Monitor
Exciter Shorted Diode Enable
43126
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Exciter Diode
Monitor
Exciter Diode Disable Level
43128
Float
4
R W
%
0–100
Exciter Diode
Monitor
Exciter Open Diode Pickup
43130
Float
4
R W
%
0–100
Exciter Diode
Monitor
Exciter Open Diode Time Delay
43132
Float
4
R W
Sec
10–60
Exciter Diode
Monitor
Exciter Shorted Diode Pickup
43134
Float
4
R W
%
0–100
Exciter Diode
Monitor
Exciter Shorted Diode Time Delay
43136
Float
4
R W
Sec
5–30
Exciter Diode
Monitor
Exciter Pole Ratio
43138
Float
4
R W
n/a
Disabled=0, 1–10
Power Input Failure
Mode
43140
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Power Input Failure
Time Delay
43142
Float
4
R W
Sec
0–10
Loss Of Sensing
Mode
43144
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Loss Of Sensing
Time Delay
43146
Float
4
R W
Sec
0–30
