Basler DECS-250 - Page 263

9440300990 28-35
DECS-250 Modbus
®
Communication
Group
Name
Register
Type
Sz
R/W
Unit
Range
Loss Of Sensing
Voltage Balanced Level
43148
Float
4
R W
%
0–100
Loss Of Sensing
Voltage Unbalanced Level
43150
Float
4
R W
%
0–100
25
Mode
43152
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Slip Angle
43156
Float
4
R W
Deg
1–99
25
Slip Frequency
43158
Float
4
R W
Hz
0.01–0.5
25
Voltage Difference
43160
Float
4
R W
%
0.1–50
25
Generator Frequency Greater Than
Bus Frequency
43162
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
Dead Voltage
43164
Float
4
R W
%
Disabled=0, 10–90
25
Live Voltage
43166
Float
4
R W
%
Disabled=0, 10–90
25
Dropout Delay
43168
Float
4
R W
ms
50–60000
25
Angle Compensation
43170
Float
4
R W
Deg
0–359.9
25
VMM Dead Line, Dead Aux
43172
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
VMM Dead Line, Live Aux
43174
Uint32
4
R W
n/a
Disabled=0 Enabled=1
25
VMM Live Line, Dead Aux
43176
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Primary Mode
43178
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Primary Pickup
43180
Float
4
R W
V
Disabled=0, 1–600000
27P
Primary Time Delay
43182
Float
4
R W
ms
100–60000
27P
Secondary Mode
43184
Uint32
4
R W
n/a
Disabled=0 Enabled=1
27P
Secondary Pickup
43186
Float
4
R W
V
Disabled=0, 1 - 600000
27P
Secondary Time Delay
43188
Float
4
R W
ms
100\–60000
59P
Primary Mode
43190
Uint32
4
R W
n/a
Disabled=0 Enabled=1
59P
Primary Pickup
43192
Float
4
R W
V
Disabled=0, 0–600000
59P
Primary Time Delay
43194
Float
4
R W
ms
100–60000
59P
Secondary Mode
43196
Uint32
4
R W
n/a
Disabled=0 Enabled=1
59P
Secondary Pickup
43198
Float
4
R W
V
Disabled=0, 0–600000
59P
Secondary Time Delay
43200
Float
4
R W
ms
100–60000
81O
Primary Mode
43202
Uint32
4
R W
n/a
Disabled=0 Over=1
81O
Primary Pickup
43204
Float
4
R W
Hz
Disabled=0, 30–70
81O
Primary Time Delay
43206
Float
4
R W
ms
100–300000
81O
Secondary Mode
43208
Uint32
4
R W
n/a
Disabled=0 Over=1
81O
Secondary Pickup
43210
Float
4
R W
Hz
Disabled=0, 30–70
81O
Secondary Time Delay
43212
Float
4
R W
ms
100–300000
81U
Primary Mode
43214
Uint32
4
R W
n/a
Disabled=0 Under=2
81U
Primary Pickup
43216
Float
4
R W
Hz
Disabled=0, 30–70
81U
Primary Time Delay
43218
Float
4
R W
ms
100–300000
81U
Primary Voltage Inhibit
43220
Float
4
R W
%
Disabled=0, 50–100
81U
Secondary Mode
43222
Uint32
4
R W
n/a
Disabled=0 Under=2
81U
Secondary Pickup
43224
Float
4
R W
Hz
Disabled=0, 30–70
81U
Secondary Time Delay
43226
Float
4
R W
ms
100–300000
81U
Secondary Voltage Inhibit
43228
Float
4
R W
%
Disabled=0, 50–100
40Q
Primary Mode
43230
Uint32
4
R W
n/a
Disabled=0 Enabled=1
40Q
Primary Pickup
43232
Float
4
R W
%
Disabled=0, 0–150
40Q
Primary Time Delay
43234
Float
4
R W
ms
Instantaneous=0, 0–300000
40Q
Secondary Mode
43236
Uint32
4
R W
n/a
Disabled=0 Enabled=1
40Q
Secondary Pickup
43238
Float
4
R W
%
Disabled=0, 0–150
40Q
Secondary Time Delay
43240
Float
4
R W
ms
Instantaneous=0, 0–300000
32R
Primary Mode
43242
Uint32
4
R W
n/a
Disabled=0 Enabled=4
32R
Primary Pickup
43244
Float
4
R W
%
Disabled=0, 0–150
32R
Primary Time Delay
43246
Float
4
R W
ms
Instantaneous =0, 0–300000
32R
Secondary Mode
43248
Uint32
4
R W
n/a
Disabled=0 Enabled=4
