Basler DECS-250 - Page 264

28-36 9440300990
Modbus
®
Communication DECS-250
Group
Name
Register
Type
Sz
R/W
Unit
Range
32R
Secondary Pickup
43250
Float
4
R W
%
Disabled=0, 0–150
32R
Secondary Time Delay
43252
Float
4
R W
ms
Instantaneous=0, 0–300000
Field Overcurrent
Timing Mode, Protection Primary
43254
Uint32
4
R W
n/a
Definite Timing=0
Inverse Timing=1
Field Overcurrent
Time Dial, Protection Primary
43256
Float
4
R W
n/a
0.1–20
Field Overcurrent
Timing Mode, Protection Secondary
43258
Uint32
4
R W
n/a
Definite Timing=0
Inverse Timing=1
Field Overcurrent
Time Dial, Protection Secondary
43260
Float
4
R W
n/a
0.1–20
24
Primary Mode
43262
Uint32
4
R W
n/a
Disabled=0,Enabled=1
24
Primary Definite Time Pickup 1
43264
Float
4
R W
n/a
0.5–6
24
Primary Definite Time Pickup 2
43266
Float
4
R W
n/a
0.5–6
24
Primary Definite Time Delay 1
43268
Float
4
R W
ms
50–600000
24
Primary Definite Time Delay 2
43270
Float
4
R W
ms
50–600000
24
Primary Inverse Time Pickup
43272
Float
4
R W
n/a
0.5–6
24
Primary Time Dial Trip
43274
Float
4
R W
n/a
0–9.9
24
Primary Time Dial Reset
43276
Float
4
R W
n/a
0–9.9
24
Primary Curve Exponent
43278
Uint32
4
R W
n/a
0.5=0,1=1,2=2
24
Secondary Mode
43280
Uint32
4
R W
n/a
Disabled=0,Enabled=1
24
Secondary Definite Time Pickup 1
43282
Float
4
R W
n/a
0.5–6
24
Secondary Definite Time Pickup 2
43284
Float
4
R W
n/a
0.5–6
24
Secondary Definite Time Delay 1
43286
Float
4
R W
ms
50–600000
24
Secondary Definite Time Delay 2
43288
Float
4
R W
ms
50–600000
24
Secondary Inverse Time Pickup
43290
Float
4
R W
n/a
0.5–6
24
Secondary Time Dial Trip
43292
Float
4
R W
n/a
0–9.9
24
Secondary Time Dial Reset
43294
Float
4
R W
n/a
0–9.9
24
Curve Exponent
43296
Uint32
4
R W
n/a
0.5=0,1=1,2=2
Gains Settings
Table 28-14. Gains Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Primary Gain Option
43800
Uint32
4
R W
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18 T'do=10.0 Te=1.67=19 T'do=10.5 Te=1.75=20
Custom=21
Secondary Gain Option
43802
Uint32
4
R W
T'do=1.0 Te=0.17=1 T'do=1.5 Te=0.25=2 T'do=2.0
Te=0.33=3 T'do=2.5 Te=0.42=4 T'do=3.0 Te=0.50=5
T'do=3.5 Te=0.58=6 T'do=4.0 Te=0.67=7 T'do=4.5
Te=0.75=8 T'do=5.0 Te=0.83=9 T'do=5.5 Te=0.92=10
T'do=6.0 Te=1.00=11 T'do=6.5 Te=1.08=12 T'do=7.0
Te=1.17=13 T'do=7.5 Te=1.25=14 T'do=8.0 Te=1.33=15
T'do=8.5 Te=1.42=16 T'do=9.0 Te=1.50=17 T'do=9.5
Te=1.58=18 T'do=10.0 Te=1.67=19 T'do=10.5 Te=1.75=20
Custom=21
AVR Kp Primary
43804
Float
4
R W
n/a
0–1000
AVR Ki Primary
43806
Float
4
R W
n/a
0–1000
AVR Kd Primary
43808
Float
4
R W
n/a
0–1000
AVR Td Primary
43810
Float
4
R W
n/a
0–1
FCR Kp
43812
Float
4
R W
n/a
0–1000
FCR Ki
43814
Float
4
R W
n/a
0–1000
FCR Kd
43816
Float
4
R W
n/a
0–1000
FCR Td
43818
Float
4
R W
n/a
0–1
FVR Kp
43820
Float
4
R W
n/a
0–1000
