Basler DECS-250 - Page 265

9440300990 28-37
DECS-250 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
FVR Ki
43822
Float
4
R W
n/a
0–1000
FVR Kd
43824
Float
4
R W
n/a
0–1000
FVR Td
43826
Float
4
R W
n/a
0–1
PF Ki
43828
Float
4
R W
n/a
0–1000
PF Kg
43830
Float
4
R W
n/a
0–1000
Var Ki
43832
Float
4
R W
n/a
0–1000
Var Kg
43834
Float
4
R W
n/a
0–1000
OEL Ki
43836
Float
4
R W
n/a
0–1000
OEL Kg
43838
Float
4
R W
n/a
0–1000
UEL Ki
43840
Float
4
R W
n/a
0–1000
UEL Kg
43842
Float
4
R W
n/a
0–1000
SCL Ki
43844
Float
4
R W
n/a
0–1000
SCL Kg
43846
Float
4
R W
n/a
0–1000
Vm Kg
43848
Float
4
R W
n/a
0–1000
Inner Loop Kp
43850
Float
4
R W
n/a
0–1000
Inner Loop Ki
43852
Float
4
R W
n/a
0–1000
AVR Kp Secondary
43854
Float
4
R W
n/a
0–1000
AVR Ki Secondary
43856
Float
4
R W
n/a
0–1000
AVR Kd Secondary
43858
Float
4
R W
n/a
0–1000
AVR Td Secondary
43860
Float
4
R W
n/a
0–1
Var Limit Ki
43862
Float
4
R W
n/a
0–1000
Var Limit Kg
43864
Float
4
R W
n/a
0–1000
AVR Primary Ka
43866
Float
4
R W
n/a
0–1
AVR Secondary Ka
43868
Float
4
R W
n/a
0–1
FCR Ka
43870
Float
4
R W
n/a
0–1
FVR Ka
43872
Float
4
R W
n/a
0–1
Grid Code Settings
Table 28-15. Grid Code Settings Group Parameters
Name
Register
Type
Bytes
R/W
Unit
Range
Grid Code Enable
44800
Uint32
4
R W
n/a
Disabled=0
Enabled=1
Grid Disconnect Time Delay
44802
Float
4
R W
Second
0–3600
Min Freq Normal
44804
Float
4
R W
Hertz
40–70
Max Freq Normal
44806
Float
4
R W
Hertz
40–70
Min V Bus Normal
44808
Float
4
R W
Per Unit
0.1–1
Max V Bus Normal
44810
Float
4
R W
Per Unit
1–1.3
Min Freq Disconnect
44812
Float
4
R W
Hertz
40–70
Max Freq Disconnect
44814
Float
4
R W
Hertz
40–70
Min V Bus Disconnect
44816
Float
4
R W
Per Unit
0.1–1
Max V Bus Disconnect
44818
Float
4
R W
Per Unit
1–1.3
PF Reference
44820
Float
4
R W
Power Factor
-1 – 1
Q Limit U Point 1
44822
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 2
44824
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 3
44826
Float
4
R W
Per Unit
0.8–1.2
Q Limit U Point 4
44828
Float
4
R W
Per Unit
0.8–1.2
Q Limit Q Point 1
44830
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 2
44832
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 3
44834
Float
4
R W
Per Unit
-0.4 – 0.4
Q Limit Q Point 4
44836
Float
4
R W
Per Unit
-0.4 – 0.4
Q(U) Slope
44838
Float
4
R W
Per Unit
0–20
