Basler DECS-250 User Manual

28-38 9440300990
Modbus
®
Communication DECS-250
Name
Register
Type
Bytes
R/W
Unit
Range
Q(U) V Bus for Zero Q
44840
Float
4
R W
Per Unit
0.9–1.1
Q(U) Deadband
44842
Float
4
R W
Per Unit
0–0.1
Q(U) Max
44844
Float
4
R W
Per Unit
-0.4 – 0.4
Q(U) Min
44846
Float
4
R W
Per Unit
-0.4 – 0.4
Q(P) Point P01
44848
Float
4
R W
Per Unit
0–1.5
Q(P) Point P02
44850
Float
4
R W
Per Unit
0–1.5
Q(P) Point P03
44852
Float
4
R W
Per Unit
0–1.5
Q(P) Point P04
44854
Float
4
R W
Per Unit
0–1.5
Q(P) Point P05
44856
Float
4
R W
Per Unit
0–1.5
Q(P) Point P06
44858
Float
4
R W
Per Unit
0–1.5
Q(P) Point P07
44860
Float
4
R W
Per Unit
0–1.5
Q(P) Point P08
44862
Float
4
R W
Per Unit
0–1.5
Q(P) Point P09
44864
Float
4
R W
Per Unit
0–1.5
Q(P) Point P10
44866
Float
4
R W
Per Unit
0–1.5
Q(P) Point Q01
44868
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q02
44870
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q03
44872
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q04
44874
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q05
44876
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q06
44878
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q07
44880
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q08
44882
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q09
44884
Float
4
R W
Per Unit
-0.7 – 0.7
Q(P) Point Q10
44886
Float
4
R W
Per Unit
-0.7 – 0.7
Remote Control Fail Mode
44888
Uint32
4
R W
n/a
Q(PF) Control=0
Hold Value=1
Remote Failure Time Delay
44890
Float
4
R W
Second
0–600
APC Enabled
44892
Uint32
4
R W
n/a
Disabled=0 Enabled=1
Active Power Input Source
44894
Uint32
4
R W
n/a
Active Power Setpoint=0
Active Power Selection=1
Active Power Setpoint
44896
Float
4
R W
Per Unit
-2 – 2
APC Normal Power Increase Rate
Percent
44898
Float
4
R W
Percent Per
Second
0.07–10
APC Normal Power Decrease Rate
Percent
44900
Float
4
R W
Percent Per
Second
0.07–10
LVRT Option
44902
Uint32
4
R W
n/a
Disabled=0
Q(PF) Control=1
Q(Voltage Limit) Control=2
Q(U) Control=3
Q(P) Control=4
Q (Third Party)=5
LVRT Enabled
44904
Uint32
4
R W
n/a
Disabled=0
Enabled=1
Time Constant for PT1
44906
Float
4
R W
Second
0.01–60
LFSM Enabled
44908
Uint32
4
R W
n/a
Disabled=0
Enabled=1
LFSM U Deadband
44910
Float
4
R W
Hertz
40–70
LFSM O Deadband
44912
Float
4
R W
Hertz
40–70
LFSM U Max Power Limit Derate
Percent
44914
Float
4
R W
Percent Per
Hertz
0–20
LFSM O Max Power Limit Derate
Percent
44916
Float
4
R W
Percent Per
Hertz
0–20
LFSM U Droop Percent
44918
Float
4
R W
Percent Per
Hertz
16.67–100
LFSM O Droop Percent
44920
Float
4
R W
Percent Per
Hertz
16.67–100
APC Kg
44922
Float
4
R W
n/a
0–100
