Basler DECS-250 - Page 267

9440300990 28-39
DECS-250 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
APC Ki
44924
Float
4
R W
n/a
0–100
APC PI Controller Max Limit
44926
Float
4
R W
Per Unit
-2 – 2
APC PI Controller Min Limit
44928
Float
4
R W
Per Unit
-2 – 2
Q(Third Party) Reference
44930
Float
4
R W
n/a
-0.45 – 0.45
Voltage Disconnect Time Delay
44932
Float
4
R W
Second
1–3600
Frequency Disconnect Time Delay
44934
Float
4
R W
Minute
1–60
Voltage Bus Time Constant
44936
Float
4
R W
Second
0.01–60
Q P Time Constant
44938
Float
4
R W
Second
0.01–60
Min Active Power Setpoint
44940
Float
4
R W
Per Unit
-2 – 2
Max Active Power Setpoint
44942
Float
4
R W
Per Unit
-2 – 2
PF Gain
44944
Float
4
R W
n/a
-100 – 100
Q Limit Gain
44946
Float
4
R W
n/a
-100 – 100
Q U Gain
44948
Float
4
R W
n/a
-100 – 100
Q Remote Gain
44950
Float
4
R W
n/a
-100 – 100
Q Limit Q Reference
44952
Float
4
R W
Per Unit
-0.45 – 0.45
Grid Reconnect Stability Timer
44954
Float
4
R W
Minute
0–30
Min Frequency Reconnect
44956
Float
4
R W
Hertz
40–70
Max Frequency Reconnect
44958
Float
4
R W
Hertz
40–70
Min V Bus Reconnect
44960
Float
4
R W
Per Unit
0.1–1
Max V Bus Reconnect
44962
Float
4
R W
Per Unit
1–1.3
Recovery Time LFSM
44964
Float
4
R W
Minute
0.1–90
Recovery Power Increase Rate Percent
44966
Float
4
R W
Percent Per
Second
0.001–10
Recovery Power Decrease Rate Percent
44968
Float
4
R W
Percent Per
Second
0.001–10
Reserved
44970-74
Active Power Level 1
44976
Float
4
R W
Per Unit
-2 – 2
Active Power Level 2
44978
Float
4
R W
Per Unit
-2 – 2
Active Power Level 3
44980
Float
4
R W
Per Unit
-2 – 2
Active Power Level 4
44982
Float
4
R W
Per Unit
-2 – 2
LFSM U Max Power Limit Start
Frequency
44984
Float
4
R W
Hertz
40–70
LFSM O Max Power Limit Start
Frequency
44986
Float
4
R W
Hertz
40–70
LFSM Power Increase Rate Percent
44988
Float
4
R W
Percent Per
Second
0.33–10
LFSM Power Decrease Rate Percent
44990
Float
4
R W
Percent Per
Second
0.33–10
APC Gain
44992
Float
4
R W
n/a
-100 – 100
Q Volt Limit Adjust Source
44994
Uint32
4
R W
n/a
None=0
Auxiliary Input=1
Modbus=2
Q U Adjust Source
44996
Uint32
4
R W
n/a
None=0
Auxiliary Input=1
Modbus=2
PF Adjust Source
44998
Uint32
4
R W
n/a
None=0
Auxiliary Input=1
Modbus=2
Q Third Party Adjust Source
45000
Uint32
4
R W
n/a
None=0
Auxiliary Input=1
Modbus=2
Active Power Adjust Source
45002
Uint32
4
R W
n/a
None=0
Auxiliary Input=1
Modbus=2
Reserved
45004
Q Volt Limit Adjust Modbus
45006
Float
4
R W
Per Unit
-0.45 – 0.45
Q U Volt Bus for Zero Q Adjust Modbus
45008
Float
4
R W
n/a
-0.5 – 0.5
