Basler DECS-250 User Manual

9440300990 28-43
DECS-250 Modbus
®
Communication
Name
Register
Type
Bytes
R/W
Unit
Range
Unit Mode Status
47572
Uint16
2
R
n/a
n/a
Control Mode Status
47573
Uint16
2
R
n/a
FCR=1 AVR=2
Internal Tracking Status
47574
Uint16
2
R
n/a
Off=0 Enabled=1
Pre-position Enable Status
47575
Uint16
2
R
n/a
n/a
Autotransfer Status
47576
Uint16
2
R
n/a
Primary=0 Secondary=1
Load Compensation Mode Status
47577
Uint16
2
R
n/a
Off=0 Droop=1 Line Drop=2
Load Compensation Mode Select
47578
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Alarm Reset Enable
47579
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Loss-of-Sensing Detection Enable
47580
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Loss-of-Sensing Triggered Transfer-to-
FCR-mode Enable
47581
Uint16
2
R W
n/a
Disabled=0 Enabled=1
Underfrequency or V/Hz Mode Enable
47582
Uint16
2
R W
n/a
UF Limiter=0 V/Hz Limiter=1
External Tracking Enabled
47583
Uint16
2
R W
n/a
Disabled=0 Enabled=1
OEL Style Virtual Toggle
47584
Uint16
2
R W
n/a
Summing=0 Takeover=1
Reserved 16bit 32
47585
Uint16
2
R W
n/a
0–65535
PF/var Option Status
47586
Uint16
2
R
n/a
Off=0 PF=1 var=2
Reserved 10
47587-620
C5
Filler
68
n/a
n/a
n/a
FCR Mode Setpoint
47621
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 47655 and 47663.
AVR Mode Setpoint
47623
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 47657 and 47665.
Var Mode Setpoint in kvar
47625
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 47659 and 47667.
PF Mode Setpoint
47627
Float
4
R W
Power
Factor
Setpoint adjustment range determined
by registers 47661 and 47669.
Droop Setting in Percent
47629
Float
4
R W
Percent
0–30
FCR Mode Traverse Rate
47631
Float
4
R W
Second
10–200
AVR Mode Traverse Rate
47633
Float
4
R W
Second
10–200
Var Mode Traverse Rate
47635
Float
4
R W
Second
10–200
PF Mode Traverse Rate
47637
Float
4
R W
Second
10–200
FCR Mode Setpoint Pre-Position
47639
Float
4
R W
Amp
Setpoint adjustment range determined
by registers 47655 and 47663.
AVR Mode Setpoint Pre-Position
47641
Float
4
R W
Volt
Setpoint adjustment range determined
by registers 47657 and 47665.
Var Mode Setpoint Pre-Position in kvar
47643
Float
4
R W
kilovar
Setpoint adjustment range determined
by registers 47659 and 47667.
PF Mode Setpoint Pre-Position
47645
Float
4
R W
Power
Factor
Setpoint adjustment range determined
by registers 47661 and 47669.
FCR Mode Setpoint Step Size
47647
Float
4
R
n/a
n/a
AVR Mode Setpoint Step Size
47649
Float
4
R
n/a
n/a
Var Mode Setpoint Step Size
47651
Float
4
R
n/a
n/a
PF Mode Setpoint Step Size
47653
Float
4
R
n/a
n/a
FCR Mode Setpoint Adjustable Minimum
47655
Float
4
R W
Percent
0–120
AVR Mode Setpoint Adjustable Minimum
47657
Float
4
R W
Percent
70–120
Var Mode Setpoint Adjustable Minimum
47659
Float
4
R W
Percent
-100 – 100
PF Mode Setpoint Adjustable Minimum
47661
Float
4
R W
Power
Factor
0.5–1
FCR Mode Setpoint Adjustable Maximum
47663
Float
4
R W
Percent
0–120
AVR Mode Setpoint Adjustable Maximum
47665
Float
4
R W
Percent
70–120
Var Mode Setpoint Adjustable Maximum
47667
Float
4
R W
Percent
-100 – 100
PF Mode Setpoint Adjustable Maximum
47669
Float
4
R W
Power
Factor
-1 – -0.5
Minimum Value for FCR Adjustable
Maximum
47671
Float
4
R
n/a
n/a
