Basler DECS-250 User Manual

28-44 9440300990
Modbus
®
Communication DECS-250
Name
Register
Type
Bytes
R/W
Unit
Range
Minimum Value for AVR Adjustable
Maximum
47673
Float
4
R
n/a
n/a
Minimum Value for Var Adjustable
Maximum
47675
Float
4
R
n/a
n/a
Mini Value for PF Adjustable Max
47677
Float
4
R
n/a
n/a
Max Value for FCR Adjustable Max
47679
Float
4
R
n/a
n/a
Max Value for AVR Adjustable Max
47681
Float
4
R
n/a
n/a
Max Value for Var Adjustable Max
47683
Float
4
R
n/a
n/a
Max Value for PF Adjustable Max
47685
Float
4
R
n/a
n/a
Step Size for FCR Adjustable Max
47687
Float
4
R
n/a
n/a
Step Size for AVR Adjustable Max
47689
Float
4
R
n/a
n/a
Step Size for Var Adjustable Max
47691
Float
4
R
n/a
n/a
Step Size for PF Adjustable Max
47693
Float
4
R
n/a
n/a
FCR Pre-Position Mode
47695
Uint16
2
R W
n/a
Maintain=0 Release=1
AVR Pre-Position Mode
47696
Uint16
2
R W
n/a
Maintain=0 Release=1
Var Pre-Position Mode
47697
Uint16
2
R W
n/a
Maintain=0 Release=1
PF Pre-Position Mode
47698
Uint16
2
R W
n/a
Maintain=0 Release=1
FCR Minimum Setpoint
47699
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47655 and 47529.
AVR Minimum Setpoint
47701
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47657 and 47525.
Var Minimum Setpoint
47703
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47659 and Rated VA.
PF Minimum Setpoint
47705
Float
4
R
n/a
Range determined by register
47661.
FCR Maximum Setpoint
47707
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47663 and 47529.
AVR Maximum Setpoint
47709
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47665 and 47525.
Var Maximum Setpoint
47711
Float
4
R
n/a
Setpoint adjustment range determined
by registers 47667 and Rated VA.
PF Maximum Setpoint
47713
Float
4
R
n/a
Range determined by register
47669.
Reserved 11
47715-740
C6
Filler
52
n/a
n/a
n/a
Soft Start Threshold
47741
Float
4
R W
Percent
0–90
Soft Start Duration
47743
Float
4
R W
Second
1–7200
Underfrequency Corner Frequency
47745
Float
4
R W
Hertz
40–75
Slope of Underfrequency Curve
47747
Float
4
R W
n/a
0–3
Width of Voltage Matching Window
47749
Float
4
R W
Percent
0–20
Voltage Matching Reference
47751
Float
4
R W
Percent
0–700
Fine Voltage Adjust Band
47753
Float
4
R W
Percent
0–30
Time Required for Loss of Sensing
47755
Float
4
R W
Second
0–30
Loss of Sensing Level Under Balanced
Conditions
47757
Float
4
R W
Percent
0–100
Loss of Sensing Level Under
Unbalanced Conditions
47759
Float
4
R W
Percent
0–100
Reserved 12
47761-800
C7
Filler
80
n/a
n/a
n/a
On-line High OEL Level
47801
Float
4
R W
Amp
0–40
Time Allowed for On-line High OEL Level
47803
Float
4
R W
Second
0–10
On-line Medium OEL Level
47805
Float
4
R W
Amp
0–30
Time Allowed for On-line Medium OEL
Level
47807
Float
4
R W
Second
0–120
On-line Low OEL Level
47809
Float
4
R W
Amp
0–20
Reserved 13
47811
Float
4
R W
var
0–99
Time Allowed for Off-line High OEL
47813
Float
4
R W
Second
0 - 10
