9440300990 29-5
DECS-250 PROFIBUS Communication
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Synchronizer Metering
Cyclic
5
Float
R
Slip Freq GG
Hz
n/a
Synchronizer Metering
Cyclic
5
Float
R
Voltage Diff GG
V
n/a
Limiter Status Cyclic
6
UINT8
R
Alarms OEL ALM
No Unit
Not Active=0, Active=1
Limiter Status Cyclic
6
UINT8
R
Alarms UEL ALM
No Unit
Not Active=0, Active=1
Limiter Status Cyclic
6
UINT8
R
Alarms SCL ALM
No Unit
Not Active=0, Active=1
Limiter Status Cyclic
6
UINT8
R
Alarms VAR
Limiter Active
No Unit
Not Active=0, Active=1
Limiter Status Cyclic
6
UINT8
R
Alarms
Underfrequency V/Hz
ALM
No Unit
Not Active=0, Active=1
HMI Indicators Cyclic
7
UINT8
R
DECSCONTROL
DECS NULL BALANCE
No Unit
Not Active=0, Active=1
HMI Indicators Cyclic
7
UINT8
R
DECSPSSMETER
DECS PSS ACTIVE
No Unit
Not Active=0, Active=1
HMI Indicators Cyclic
7
UINT8
R
DECSREGULATORMETER
DECS
INTERNAL TRACKING
ACTIVE
No Unit
Not Active=0, Active=1
HMI Indicators Cyclic
7
UINT8
R
DECSCONTROL DECS
PREPOSITION
No Unit
Active setpoint is not at a pre-
position value=0, Active setpoint is
at a pre-position value=1
HMI Indicators Cyclic
7
UINT8
R
DECSREGULATORMETER
SETPOINT
AT LOWER LIMIT
No Unit
Active setpoint is not at minimum
value=0, Active setpoint is at
minimum value=1
HMI Indicators Cyclic
7
UINT8
R
DECSREGULATORMETER
SETPOINT
AT UPPER LIMIT
No Unit
Active setpoint is not at maximum
value=0, Active setpoint is at
maximum value=1
Controller Status Cyclic
8
UINT8
R
DECSCONTROL IN AVR
MODE
No Unit
Not in AVR mode=0, In AVR
mode=1
Controller Status Cyclic
8
UINT8
R
DECSCONTROL IN FCR
MODE
No Unit
Not in FCR mode=0, In FCR
mode=1
Controller Status Cyclic
8
UINT8
R
DECSCONTROL IN FVR
MODE
No Unit
Not in FVR mode=0, In FVR
mode=1
Controller Status Cyclic
8
UINT8
R
DECSCONTROL IN PF
MODE
No Unit
Not in PF mode=0, In PF mode=1
Controller Status Cyclic
8
UINT8
R
DECSCONTROL IN VAR
MODE
No Unit
Not in var mode=0, In var mode=1
System Status Cyclic
9
UINT8
R
DECSCONTROL DECS
START STOP
No Unit
Stopped=0, Started=1
System Status Cyclic
9
UINT8
R
ALARMS IFLIMIT
No Unit
No field short circuit condition=0,
Field short circuit condition=1
System Status Cyclic
9
UINT8
R
DECSCONTROL DECS
SOFT START ACTIVE
No Unit
Not in soft start=0, In soft start=1
System Status Cyclic
9
UINT8
R
ALARMREPORT
ALARMOUTPUT
No Unit
No active alarms=0, Active
alarms=1
System Status Cyclic
9
UINT8
R
DECSCONTROL DECS PF
VAR
ENABLE 52 J K
No Unit
PF/var not enabled via PLC=0,
PF/var enabled via PLC=1
System Status Cyclic
9
UINT8
R
DECSCONTROL DECS
PARALLEL
ENABLE 52 L M
No Unit
Parallel not enabled via PLC=0,
Parallel enabled via PLC=1
Local Contact Inputs Cyclic
10
UINT8
R
CONTACTINPUTS
STARTINPUT
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
CONTACTINPUTS
STOPINPUT
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
Contact Inputs Input 1
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
Contact Inputs Input 2
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
Contact Inputs Input 3
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
Contact Inputs Input 4
No Unit
Open=0, Closed=1
Local Contact Inputs Cyclic
10
UINT8
R
Contact Inputs Input 5
No Unit
Open=0, Closed=1
