DECS-250 PROFIBUS Communication
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Gen Metering
16
Float
R
VBC GG (Gen Voltage
Magnitude)
V
0 - 2000000000
Gen Metering
16
Float
R
VCA GG (Gen Voltage
Magnitude)
V
0 - 2000000000
Gen Metering
16
Float
R
VAB GG (Gen Voltage
Angle)
Deg
0 - 360
Gen Metering
16
Float
R
VBC GG (Gen Voltage
Angle)
Deg
0 - 360
Gen Metering
16
Float
R
VCA GG (Gen Voltage
Angle)
Deg
0 - 360
Gen Metering
16
Float
R
IA GG (Gen Current
Magnitude)
Amp
0 - 2000000000
Gen Metering
16
Float
R
IB GG (Gen Current
Magnitude)
Amp
0 - 2000000000
Gen Metering
16
Float
R
IC GG (Gen Current
Magnitude)
Amp
0 - 2000000000
Gen Metering
16
Float
R
IA GG (Gen Current Angle)
Deg
0 - 360
Gen Metering
16
Float
R
IB GG (Gen Current Angle)
Deg
0 - 360
Gen Metering
16
Float
R
IC GG (Gen Current Angle)
Deg
0 - 360
Gen Metering
16
Float
R
IAVG GG
Amp
0 - 2000000000
Gen Metering
16
Float
R
Freq GG
Hz
10 - 180
Gen Metering Per Unit
17
Float
R
Vab pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Vbc pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Vca pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Vavg pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Ia pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Ib pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Ic pu GG
Per Unit
-10 - 10
Gen Metering Per Unit
17
Float
R
Iavg pu GG
Per Unit
-10 - 10
Power Metering
18
Float
R
Total Watts AVG GG
Watt
-3.00E+14 - 3.00E+14
Power Metering
18
Float
R
Total VARS AVG GG
var
-3.00E+14 - 3.00E+14
Power Metering
18
Float
R
Total S GG
VA
-3.00E+14 - 3.00E+14
Power Metering
18
Float
R
Total PF GG
PF
-1 - 1
Power Metering
18
Float
R
POS Watthour Total GG
watthour
0.00E+00 - 1.00E+09
Power Metering
18
Float
R
POS varhour Total GG
varhour
0.00E+00 - 1.00E+09
Power Metering
18
Float
R
NEG Watthour Total GG
watthour
-1.00E+09 - 0.00E+00
Power Metering
18
Float
R
NEG varhour Total GG
varhour
-1.00E+09 - 0.00E+00
Power Metering Per Unit
19
Float
R
kW pu GG
Per Unit
-10 - 10
Power Metering Per Unit
19
Float
R
kVA pu GG
Per Unit
-10 - 10
Power Metering Per Unit
19
Float
R
kvar pu GG
Per Unit
-10 - 10
Bus Metering
20
Float
R
VAB GG (Bus Voltage
Magnitude)
V
0 - 2000000000
Bus Metering
20
Float
R
VBC GG (Bus Voltage
Magnitude)
V
0 - 2000000000
Bus Metering
20
Float
R
VCA GG (Bus Voltage
Magnitude)
V
0 - 2000000000
Bus Metering
20
Float
R
VAB GG (Bus Voltage
Angle)
Deg
0 - 360
Bus Metering
20
Float
R
VBC GG (Bus Voltage
Angle)
Deg
0 - 360
Bus Metering
20
Float
R
VCA GG (Bus Voltage
Angle)
Deg
0 - 360
Bus Metering
20
Float
R
Freq GG
Hz
10 - 180
Bus Metering Per Unit
21
Float
R
Bus Vab pu GG
Per Unit
-10 - 10
Bus Metering Per Unit
21
Float
R
Bus Vbc pu GG
Per Unit
-10 - 10
