29-8 9440300990
PROFIBUS Communication DECS-250
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Bus Metering Per Unit
21
Float
R
Bus Vca pu GG
Per Unit
-10 - 10
Bus Metering Per Unit
21
Float
R
Bus Vavg pu GG
Per Unit
-10 - 10
Field Metering
22
Float
R
VX GG
V
-1000 - 1000
Field Metering
22
Float
R
IX GG
Amp
0 - 2000000000
Field Metering
22
Float
R
EDM Ripple Percent GG
%
n/a
PSS Metering
23
Float
R
V1 GG
V
0 - 2000000000
PSS Metering
23
Float
R
V2 GG
V
0 - 2000000000
PSS Metering
23
Float
R
I1 GG
Amp
0 - 2000000000
PSS Metering
23
Float
R
I2 GG
Amp
0 - 2000000000
PSS Metering
23
Float
R
Term Freq DEV GG
Percent
n/a
PSS Metering
23
Float
R
Comp Freq DEV GG
Percent
n/a
PSS Metering
23
Float
R
PSS Output GG
No Unit
n/a
PSS Metering Per Unit
24
Float
R
Pos Seq V pu GG
Per Unit
-10 - 10
PSS Metering Per Unit
24
Float
R
Neq Seq V pu GG
Per Unit
-10 - 10
PSS Metering Per Unit
24
Float
R
Pos Seq I pu GG
Per Unit
-10 - 10
PSS Metering Per Unit
24
Float
R
Neq Seq I pu GG
Per Unit
-10 - 10
Synchronization
25
Float
R
Slip Angle GG
Deg
-359.9 - 359.9
Synchronization
25
Float
R
Slip Freq GG
Hz
n/a
Synchronization
25
Float
R
Voltage Diff GG
V
n/a
Aux Input Metering
26
Float
R
Value GG (Aux Input
Voltage)
V
-9999999 - 9999999
Aux Input Metering
26
Float
R
Value GG (Aux Input
Current)
Amp
-9999999 - 9999999
Tracking
27
Float
R
Tracking Error GG
%
n/a
Tracking Status
28
UINT8
R
DECS Regulator Meter
DECS
Internal Tracking Active
No Unit
Not active=0, Active=1
Tracking Status
28
UINT8
R
DECS Regulator Meter
DECS
External Tracking Active
No Unit
Not active=0, Active=1
Tracking Status
28
UINT8
R
DECS Control DECS Null
Balance
No Unit
Not active=0, Active=1
Control Panel Setpoint
Metering
29
Float
R
Gen Voltage Setpoint GG
No Unit
84 - 144
Control Panel Setpoint
Metering
29
Float
R
Excitation Current Setpoint
GG
No Unit
0 - 12
Control Panel Setpoint
Metering
29
Float
R
Excitation Voltage Setpoint
GG
No Unit
0 - 75
Control Panel Setpoint
Metering
29
Float
R
Gen Var Setpoint GG
No Unit
0 – 41.57
Control Panel Setpoint
Metering
29
Float
R
Gen Pf Setpoint GG
No Unit
0.5 – -0.5
Control Panel Status
30
UINT8
R
DECS Control DECS Start
Stop
No Unit
Stopped=0, Started=1
Control Panel Status
30
UINT8
R
DECS Control DECS is in
Automatic Mode
No Unit
Not in automatic=0, In automatic=1
Control Panel Status
30
UINT8
R
DECS Control DECS is in
Manual Mode
No Unit
Not in manual=0, In manual=1
Control Panel Status
30
UINT8
R
DECS Control DECS FCR
Controller Active
No Unit
FCR not active=0, FCR active=1
Control Panel Status
30
UINT8
R
DECS Control DECS FVR
Controller Active
No Unit
FVR not active=0, FVR active=1
Control Panel Status
30
UINT8
R
DECS Control DECS VAR
Controller Active
No Unit
VAR not active=0, VAR active=1
Control Panel Status
30
UINT8
R
DECS Control DECS PF
Controller Active
No Unit
PF not active=0, PF active=1
