DECS-250 PROFIBUS Communication
Preposition 1 Active
Active setpoint is not at pre-position
1 value=0, Active setpoint is at pre-
Preposition 2 Active
Active setpoint is not at pre-position
2 value=0, Active setpoint is at pre-
Preposition 3 Active
Active setpoint is not at pre-position
3 value=0, Active setpoint is at pre-
Alarm Report Alarm Output
No active alarms=0, Active
alarms=1
DECS PSS Meter DECS
PSS Active
PSS not active=0, PSS active=1
DECS Control DECS
Null Balance
Alarms VAR LIMITER
ACTIVE
Alarms VOLTAGE
MATCHING ACTIVE
Soft Start Select
Primary settings active=0,
Secondary settings active=1
PSS
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
DECS Control DECS OEL
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
DECS Control DECS UEL
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
DECS Control DECS SCL
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
Protect
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
DECS Control DECS PID
Select Secondary Settings
Primary settings active=0,
Secondary settings active=1
Limiter Select
Primary settings active=0,
Secondary settings active=1
Preposition
Active setpoint is not at a pre-
position value=0, Active setpoint is
at a pre-position value=1
DECS Control DECS VAR
Controller Active
VAR not active=0, VAR active=1
DECS Control DECS PF
Controller Active
PF not active=0, PF active=1
DECS Control DECS Auto
Mode Enable
Auto mode not enabled via PLC=0,
Auto mode enabled via PLC=1
Manual
Manual mode not enabled via
PLC=0, Manual mode enabled via
DECS Control DECS FVR
Controller Active
FVR not active=0, FVR active=1
