Basler DECS-250 - Page 290

29-14 9440300990
PROFIBUS Communication DECS-250
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
AEM RTD Input Status
37
UINT8
R
RTD Protection 6 Thresh 3
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 6 Thresh 4
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 7 Thresh 1
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 7 Thresh 2
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 7 Thresh 3
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 7 Thresh 4
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 8 Thresh 1
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 8 Thresh 2
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 8 Thresh 3
Trip
No Unit
Not tripped=0, Tripped=1
AEM RTD Input Status
37
UINT8
R
RTD Protection 8 Thresh 4
Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Meter
38
Float
R
Thermocouple Input 1 Raw
Value GG
mV
n/a
AEM TC Input Meter
38
Float
R
Thermocouple Input 2 Raw
Value GG
mV
n/a
AEM TC Input Meter
38
Float
R
Thermocouple Input 1
Scaled Value GG
Deg F
n/a
AEM TC Input Meter
38
Float
R
Thermocouple Input 2
Scaled Value GG
Deg F
n/a
AEM TC Input Status
39
UINT8
R
AEM Config Thermocouple
1
Out of Range
No Unit
Value in range=0, Value out of
range=1
AEM TC Input Status
39
UINT8
R
AEM Config Thermocouple
2
Out of Range
No Unit
Value in range=0, Value out of
range=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 1
Thresh 1 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 1
Thresh 2 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 1
Thresh 3 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 1
Thresh 4 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 2
Thresh 1 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 2
Thresh 2 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 2
Thresh 3 Trip
No Unit
Not tripped=0, Tripped=1
AEM TC Input Status
39
UINT8
R
Thermocouple Protection 2
Thresh 4 Trip
No Unit
Not tripped=0, Tripped=1
Contact Output Status
40
UINT8
R
Contact Outputs
Watchdog Output
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 1
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 2
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 3
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 4
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 5
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 6
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 7
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 8
No Unit
Open=0, Closed=1
