DECS-250 PROFIBUS Communication
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Contact Output Status
40
UINT8
R
Contact Outputs Output 9
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 10
No Unit
Open=0, Closed=1
Contact Output Status
40
UINT8
R
Contact Outputs Output 11
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 1
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 2
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 3
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 4
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 5
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 6
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 7
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 8
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 9
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 10
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 11
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 12
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 13
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 14
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 15
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 16
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 17
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 18
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 19
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 20
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 21
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 22
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 23
No Unit
Open=0, Closed=1
CEM Output Status
41
UINT8
R
CEM Output 24
No Unit
Open=0, Closed=1
AEM Analog Output Meter
42
Float
R
Analog Output 1 Raw Value
GG
No Unit
0 – 10 V or 4 – 20 mA
AEM Analog Output Meter
42
Float
R
Analog Output 2 Raw Value
GG
No Unit
0 – 10 V or 4 – 20 mA
AEM Analog Output Meter
42
Float
R
Analog Output 3 Raw Value
GG
No Unit
0 – 10 V or 4 – 20 mA
AEM Analog Output Meter
42
Float
R
Analog Output 4 Raw Value
GG
No Unit
0 – 10 V or 4 – 20 mA
AEM Analog Output Meter
42
Float
R
Analog Output 1 Scaled
Value GG
No Unit
n/a
AEM Analog Output Meter
42
Float
R
Analog Output 2 Scaled
Value GG
No Unit
n/a
AEM Analog Output Meter
42
Float
R
Analog Output 3 Scaled
Value GG
No Unit
n/a
AEM Analog Output Meter
42
Float
R
Analog Output 4 Scaled
Value GG
No Unit
n/a
AEM Analog Output Status
43
UINT8
R
Remote Analog Output 1
Out of Range
No Unit
Value in range=0, Value out of
range=1
AEM Analog Output Status
43
UINT8
R
Remote Analog Output 2
Out of Range
No Unit
Value in range=0, Value out of
range=1
AEM Analog Output Status
43
UINT8
R
Remote Analog Output 3
Out of Range
No Unit
Value in range=0, Value out of
range=1
AEM Analog Output Status
43
UINT8
R
Remote Analog Output 4
Out of Range
No Unit
Value in range=0, Value out of
range=1
Config. Prot. Status
44
UINT8
R
Configurable Protection 1
Configurable Protection
Threshold 1 Trip
No Unit
Not tripped=0, Tripped=1
