29-24 9440300990
PROFIBUS Communication DECS-250
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
OEL Scaling
123
UINT32
R/W
OEL Scale Enable GG
No Unit
DISABLED=0
Auxiliary Input=1
AEM RTD 1=2
AEM RTD 2=3
AEM RTD 3=4
AEM RTD 4=5
AEM RTD 5=6
AEM RTD 6=7
AEM RTD 7=8
AEM RTD 8=9
OEL Scaling
124
Float
R/W
OEL Scale Summing
Signal1 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Summing
Signal2 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Summing
Signal3 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Summing
Scale1 GG
%
0 - 200
OEL Scaling
124
Float
R/W
OEL Scale Summing
Scale2 GG
%
0 - 200
OEL Scaling
124
Float
R/W
OEL Scale Summing
Scale3 GG
%
0 - 200
OEL Scaling
124
Float
R/W
OEL Scale Takeover
SIGNAL1 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Takeover
Signal2 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Takeover
Signal3 GG
V
-10 - 10
OEL Scaling
124
Float
R/W
OEL Scale Takeover
Scale1 GG
%
0 - 200
OEL Scaling
124
Float
R/W
OEL Scale Takeover
Scale2 GG
%
0 - 200
OEL Scaling
124
Float
R/W
OEL Scale Takeover
Scale3 GG
%
0 - 200
SCL Scaling
125
UINT32
R/W
SCL Scale Enable GG
No Unit
DISABLED=0
Auxiliary Input=1
AEM RTD 1=2
AEM RTD 2=3
AEM RTD 3=4
AEM RTD 4=5
AEM RTD 5=6
AEM RTD 6=7
AEM RTD 7=8
AEM RTD 8=9
SCL Scaling
126
Float
R/W
SclScaleSignal1 GG
V
-10 - 10
SCL Scaling
126
Float
R/W
SclScaleSignal2 GG
V
-10 - 10
SCL Scaling
126
Float
R/W
SclScaleSignal3 GG
V
-10 - 10
SCL Scaling
126
Float
R/W
SclScalePoint1 GG
%
0 - 200
SCL Scaling
126
Float
R/W
SclScalePoint2 GG
%
0 - 200
SCL Scaling
126
Float
R/W
SclScalePoint3 GG
%
0 - 200
Underfrequency/Volts per
hertz
127
UINT32
R/W
Sys Option Under Freq
Mode GG
No Unit
UF Limiter=0 V2H Limiter=1
Underfrequency /Volts per
Hertz
128
Float
R/W
Sys Option Under Freq
Hz GG
Hz
40 - 75
Underfrequency /Volts per
Hertz
128
Float
R/W
Sys Option Under Freq
Slope GG
No Unit
0 - 3
Underfrequency /Volts per
Hertz
128
Float
R/W
Sys Option Voltage Per Hz
Slope Hi GG
No Unit
0 - 3
Underfrequency /Volts per
Hertz
128
Float
R/W
Sys Option Voltage Per Hz
Slope Lo GG
No Unit
0 - 3
Underfrequency /Volts per
Hertz
128
Float
R/W
Sys Option Voltage Per Hz
Slope Time GG
Sec
0 - 10
PSS Configure
129
UINT32
R/W
Sys Option PSS
Power Level
Enable GG
No Unit
Disabled=0 Enabled=1
