Basler DECS-250 - Page 304

29-28 9440300990
PROFIBUS Communication DECS-250
Instance Name
Inst. #
Type
RW
Key Name
Unit
Range
Synchronizer
151
UINT32
R/W
Sync Type GG
No Unit
Anticipatory=0 Phase Lock Loop=1
Synchronizer
151
UINT32
R/W
Fgen GT Fbus GG
No Unit
Disabled=0 Enabled=1
Synchronizer
151
UINT32
R/W
Vgen GT Vbus GG
No Unit
Disabled=0 Enabled=1
Synchronizer
152
Float
R/W
Slip Frequency GG
Hz
0.1 - 0.5
Synchronizer
152
Float
R/W
Voltage Window GG
%
2 - 15
Synchronizer
152
Float
R/W
Breaker Closing
Angle GG
Deg
3 - 20
Synchronizer
152
Float
R/W
Sync Activation
Delay GG
Sec
0.1 - 0.8
Synchronizer
152
Float
R/W
Sync Fail Activation
Delay GG
Sec
0.1 - 600
Synchronizer
152
Float
R/W
Sync Speed Gain GG
No Unit
0.001 - 1000
Synchronizer
152
Float
R/W
Sync Voltage Gain GG
No Unit
0.001 - 1000
Voltage Matching
153
UINT32
R/W
Sys Option Input Volt
Match Enabled GG
No Unit
Disabled=0 Enabled=1
Voltage Matching
154
Float
R/W
Sys Option Voltage Match
Band GG
%
0 - 20
Voltage Matching
154
Float
R/W
Sys Option Voltage Match
Ref GG
%
0 - 700
Breaker Hardware
155
UINT32
R/W
Gen Breaker GG
No Unit
Not Configured=0 Configured=1
Breaker Hardware
155
UINT32
R/W
Gen Contact Type GG
No Unit
Pulse=0 Continuous=1
Breaker Hardware
155
UINT32
R/W
Dead Bus Close
Enable GG
No Unit
Disabled=0 Enabled=1
Breaker Hardware
155
UINT32
R/W
Dead Gen Close
Enable GG
No Unit
Disabled=0 Enabled=1
Breaker Hardware
156
Float
R/W
Breaker Close
Wait Time GG
Sec
0.1 - 600
Breaker Hardware
156
Float
R/W
Gen Open Pulse
Time GG
Sec
0.01 - 5
Breaker Hardware
156
Float
R/W
Gen Close Pulse
Time GG
Sec
0.01 - 5
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Dead Gen
Threshold GG
V
0 - 600000
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Dead Gen
Time Delay GG
Sec
0.1 - 600
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Over
Voltage Pickup GG
V
10 - 600000
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Over
Voltage Dropout GG
V
10 - 600000
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Under
Voltage Pickup GG
V
10 - 600000
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Under
Voltage Dropout GG
V
10 - 600000
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable
Over Frequency
Pickup GG
Hz
46 - 64
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable
Over Frequency
Dropout GG
Hz
46 - 64
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable
Under Frequency
Pickup GG
Hz
46 - 64
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable
Under Frequency
Dropout GG
Hz
46 - 64
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Activation
Delay GG
Sec
0.1 - 600
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Failed Activation
Delay GG
Sec
0.1 - 600
Bus Condition Detection
(Gen Sensing)
158
Float
R/W
Gen Stable Low Line
Scale Factor GG
No Unit
0.001 - 3
