Basler DECS-250 - Mounting

9440300990 33-3
DECS-250 Contact Expansion Module
This product conforms to the following Harmonized Standards:
• EN 50178:1997 - Electronic Equipment for use in Power Installations
• EN 61000-6-4:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Emission Standard
for Industrial Environments
• EN 61000-6-2:2001 - Electromagnetic Compatibility (EMC), Generic Standards, Immunity for
Industrial Environments
• EN 50581:2012, Ed. 12 - Technical Documentation for the Assessment of Electrical and Electronic
Products with respect to the Restriction of Hazardous Substances.
EAC Mark (Eurasian Conformity)
• TP TC 004/2011
• TP TC 020/2011
Physical
Weight
CEM-2020 ............................ 2.25 lb (1.02 kg)
CEM-2020H ......................... 1.90 lb (0.86 kg)
Dimensions................................. See Installation later in this chapter.
Installation
Contact Expansion Modules are delivered in sturdy cartons to prevent shipping damage. Upon receipt of
a module, check the part number against the requisition and packing list for agreement. Inspect for
damage, and if there is evidence of such, immediately file a claim with the carrier and notify the Basler
Electric regional sales office, your sales representative, or a sales representative at Basler Electric,
Highland, Illinois USA.
If the device is not installed immediately, store it in the original shipping package in a moisture- and dust-
free environment.
Mounting
Contact Expansion Modules are contained in a potted plastic case and may be mounted in any
convenient position. The construction of a Contact Expansion Module is durable enough to mount directly
on a genset using ¼-inch hardware. Hardware selection should be based on any expected
shipping/transportation and operating conditions. The torque applied to the mounting hardware should not
exceed 65 in-lb (7.34 N•m).
See Figure 33-1 for CEM-2020 overall dimensions. All dimensions are shown in inches with millimeters in
parenthesis.
