Page 16 For technical questions, please call 1-888-866-5797. 70813
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Flat Key (type C) 1
2 Motor Pulley 1
3 Bolt 13
4 Motor Components 1
5 Bolt 4
6 Dust Outlet 1
7 Driving Axle 1
8 Nut 4
9 Spring Washer 14
10 Flat Washer 58
11 Screw (A) 1
12 Cross Recessed Pan
Head Tapping Screw
2
13 Guide Rod 1
14 Angular Adjusting
Shim
1
15 Set Screw 3
16 Pointer Spring 1
17 Steel Ball 1
18 Angler Pointer 1
19 Friction Pad 3
20 Goniometer 1
21 Arm pointer 1
22 Cross recessed
pan head screw
1
23 Brush screw 1
24 Brush 1
25 Set (A) 1
26 Large Flat Pad 4
27 Hex Lock Nut 7
28 Large Flat Pad 3
29 Angler Mounting Base 1
30 Bolt 1
31 Pusher Bar 1
32 Fine Adjustment
Locking Handle
1
33 Adjusting Pinch 1
34 Angler Locking
Handle
1
35 Handle Cover 2
36 Bolt 1
37 Power Cord
38 Tensioning Lever
Handle Seat
1
39 Tensioning Eccentric 1
40 Tensioning Handle 1
41 Tensioning
Handle Cover
1
42 Column Plug 1
43 Bearing Adjustment
Handle
4
44 Set (B) 5
45 Bearing 5
46 Flat Washer 9
47 Cylindrical Pin (B) 3
48 Screw (C) 1
Part Description Qty
49 Cylindrical Pin (A) 1
50 Fixed Seat (B) 1
51 Fixed Seat (A) 1
52 Set Screw 3
53 Locking Block 1
54 Lifting Body 1
55 Rack 1
56 Handle Spring 1
57 Locking Handle 1
58 Angle Adjusting Gear 1
59 Angle Locking
Handle Nut
1
60 Buffer Cap 1
61 Set Screw 1
62 Tension Ring 1
63 Hex Lock Nut 43
64 Rear Guide Rail
Plug (left)
2
65 Cross Countersunk
Head Tapping Screw
4
66 Rear Ruler Seat 1
67 Bolt 1
68 Work Table 1
69 Strip Guard 1
70 Ruler Seat Plug (left) 1
71 Guide Rail 1
72 Scale Plate 1
73 Ruler Seat Plug (right) 1
74 Needle Bearing 1
75 Bearing Shaft 1
76 Clip 1
77 Positioning Block 1
78 Cylindrical Pin 1
79 Bolt 2
80 Bolt 5
81 Cross Pan
Head Screw
1
82 Scale Pointer 1
83 Guide Pipe
Fixing Seat
1
84 Cylindrical Pin 1
85 Cylindrical Pin 1
86 Steel Ball 1
87 Pointer Spring 1
88 Screw 1
89 Clamping
Handle Cover
1
90 Clamping Handle (B) 1
91 Nut 1
92 Eccentric Wheel 1
93 Locking Plate 1
94 Cross Pan
Head Screw
4
95 Flat Washer 10
96 Spring Plate 1
97 Spring Washer 4
Part Description Qty
98 Nut 4
99 Locking Plate
Spring Plate
1
100 Cross Pan
Head Screw
2
101 Guide Seat
Friction Pad
1
102 Guide Tube Screw 1
103 Guide Tube 1
104 Screw (C) 1
105 Guide Tube Roller 1
106 Rear Clamping Seat 1
107 Rear Locking Plate 1
108 Guide System Spring 1
109 Cylindrical Pin 1
110 Screw 4
111 Spring Washer 4
112 Flat Washer 4
113 Shaft Ring 1
114 Angle Locking Screw 1
115 Angle Set Screw 2
116 Lock Handle 4
117 Fixed Base 1
118 Angle Adjusting Plate 2
119 Eccentric Stopper 1
120 Bolt 4
121 Angle Adjusting
Seat Assembly
1
122 Bolt 2
123 Handle 1
124 N/A
125 Tensioning Screw 1
126 Tension Spring 1
127 Tensioning Block 1
128 Bolt 3
129 Support Rod 3
130 Tension Indicator Rod 1
131 Pointer Screw 2
132 Tensioning Pointer 1
133 Pointer Nut 1
134 Clip 2
135 Upper Pulley
Fixing Seat
2
136 Tension Rod 1
137 Tensioning Block (B) 1
138 Rotating Shaft 1
139 Upper Pulley Shaft 1
140 Bearing 4
141 Retaining Ring 4
142 Shaft Ring 3
143 Saw Blade 1
144 Pulley 2
145 Locking Pinch 1
146 Locking Hand Spring 1
147 Pulley Pad 1
148 Lifting Handle 1
Parts List and Diagram
Parts List
