Page 11For technical questions, please call 1-888-866-5797.70813
SAFETYOPERATIONMAINTENANCE SETUP
Saw Blade Tracking and Tensioning
1. Disconnect Band Saw from power source.
2. Open upper and lower Wheel Cover.
3. Make sure that Blade Tension Release
Lever is in tighten position.
4. Rotate Blade Tracking Lock Handle
counterclockwise, see Figure A.
CAUTION! Do not touch Blade with hands.
5. Manually rotate upper Wheel and turn Blade
Tracking Adjustment Handle until Blade is
centered over upper and lower Wheels.
6. Rotate Blade Tracking Lock Handle
clockwise to tighten, see Figure A.
7. Rotate Blade Tensioning Handle until desired
blade tension reached, see Figure A. View tension
scale through window in Upper Wheel Cover.
8. Close upper and lower Wheel Covers.
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical
outlet before performing any procedure in this section.
TO PREVENT SERIOUS INJURY:
DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR REMOVED.
TO PREVENT INJURY:
Wear heavy-duty work gloves and ANSI-approved safety goggles whenever
handling blade. DO NOT WEAR GLOVES WHILE SAWING.
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route to reach
the work area without creating a tripping hazard or
exposing the power cord to possible damage. The
power cord must reach the work area with enough
extra length to allow free movement while working.
3. Secure loose workpieces using a vise or
clamps (not included) to prevent movement
while working. A workpiece that hangs
over the edge of the Work Table 5 inches or
more needs to be supported properly.
4. There must not be objects, such as utility lines,
nearby that will present a hazard while working.
Upper and Lower Blade Guide Adjustment
Note: The height of the Blade Guard should be
adjusted prior to every operation to accommodate the
height of the work piece. The Blade Guard should be no
more than 1/8″ from the upper edge of the workpiece.
Upper Blade Guide
1. Loosen two Lock Handles.
2. Adjust Guide Bearings so that they are equal
or less than 0.030″ away from Blade.
3. Tighten two Lock Handles.
4. Loosen the Socket Head Bolt.
5. Adjust Thrust Bearing so it is equal or less
than 0.040″ away from back of blade.
6. Tighten Socket Head Bolt.
7. Loosen Blade Guard Lock Handle.
To Next Page
