Baumer GXMMW User Manual

Manual_ProfibusDPV2_BIDE_EN.docx 23/41 Baumer IVO GmbH & Co. KG
22.11.12 Villingen-Schwenningen, Germany
Parameter 918 (read only) Profibus node ID (BCD switches)
Parameter 922 (read only) Telegram type (=81)
Parameter 964 (read only) Device identification
Parameter 965 (read only) Profile number (3.2)
Parameter 971 (read/write) Transfer to non-volatile memory
Parameter 979 (read only) Sensor format
Parameter 65000 (read/write) Preset value
All parameters are accessed by Slot 1 (indicate E/A address under „ID“ in Step7), index 47 and subindex 0.
Additional access to block 0 of I&M functions (Identification and Maintenance ) via index 255, Slot 0 or 1,
parameter 65000.
6.9.4. PROFIdrive parameter 918 PROFIBUS node ID
Readout of the PROFIBUS node ID (BCD switch). Example node ID: 55 (0x37)
DS_WRITE
DP-V1 Header
Called parameter
Value
Example
Function ID
Permanent for DS_Write
0x5F
ID
Slot no.1 (E/A address telegram81)
0x0200
Index
47 = 0x2F
0x2F
Length
10 = 0x0A
0x0A
Data Unit - (write):
Byte #
Example
0
Request Reference (Example)
0xAA
1
Request ID=0x01 Change ID=0x02
0x01
2
Shaft no. (0=whole device)
0x00
3
Number of parameters
0x01
4
Attribute = “Value”
0x10
5
Number of parameter elements
0x01
6
Prm_no hi: 918 = 0x0396
0x03
7
Prm_no lo: 918 = 0x0396
0x96
8
Subindex hi
0x00
9
Subindex lo
0x00
DS_READ
DP-V1 Header
Called parameter
Value
Function ID
Permanent for DS_Read
0x5E
ID
Slot no.1 (E/A address telegram81)
0x0200
Index
47 = 0x2F
0x2F
Max.length
64 = 0x40
0x40
Data Unit - (read):
Byte #
Example
0
Request Reference: mirrored
0xAA
1
Request ID (not: Change)
0x01
2
Shaft no. (0=whole device)
0x00
3
Number of parameters
0x01
4
Format: Unsigned16
0x06
5
Number of values
0x01
6
Value (hi): ever 0
0x00
7
Value (lo): Node address
0x37
