6.9.7. PROFIdrive parameter 965 profile number
Readout of the profile number. The encoder relates to the DPV2 encoder profile (PNO Order Nr 3.162),
version V3.2 of December 2004. For this reason the value replied is ever 0x03, 0x02.
DS_WRITE
DP-V1 Header
Called up
parameter
Value
Example
Function ID
Permanent for DS_Write
0x5F
ID
Slot no.1 (E/A address telegram81)
0x0200
Index
47 = 0x2F
0x2F
Length
8 = 0x08
0x08
Data Unit - (write):
Byte #
Example
0
Request Reference (example)
0xAA
1
Request ID=0x01 Change ID=0x02
0x01
2
Shaft no. (0=whole device)
0x00
3
Number of parameters
0x01
4
Attribute = “Value”
0x10
5
Number of parameter elements
0x01
6
Prm_no hi: 965 = 0x03C5
0x03
7
Prm_no lo: 965 = 0x03C5
0xC5
DS_READ
DP-V1 Header
Called parameter
Value
Function ID
Permanent for DS_Read
0x5E
ID
Slot no.1 (E/A address telegram81)
0x0200
Index
47 = 0x2F
0x2F
Max.Length
64 = 0x40
0x40
Data Unit - (read):
Byte #
Example
0
Request Reference: mirrored
0xAA
1
Request ID
0x01
2
Shaft no. (0=whole device)
0x00
3
Number of parameters
0x01
4
Format: Unsigned16
0x06
5
Number of values
0x01
6
Profile number (hi)
0x03
7
Profile number (lo)
0x02
