10.3.3 Checking the flue gas discharge and the air supply
Heat the water in the boiler to a temperature of approx. 70 °C.
Unscrew the plug of the flue gas measurement point (exhaust system
adaptor).
Measure the content of O
2
/CO
2
in the flue gas using the measuring
equipment. Compare this with the control value.
10.3.5 Checking the automatic air vent
10.3.4 Checking the combustion
Measure the O
2
/CO
2
contents and the temperature of the flue gases at the
flue gas measuring point. To do this, proceed as follows:
The front panel must be removed to extract the siphon (A). Proceed as
described below:
Remove the screw (2);
Remove the clip (1);
Unfasten the pipe from the heat exchanger (4);
Remove the siphon (3) and clean it;
Replace, if necessary, all the gaskets present;
Fill the siphon with water.
Assembly is the reverse of the above steps.
Ensure the trap breather pipe is clipped as shown to
the drip tray tube.
Fig.69 Dismantling the siphon
Verify the distances between the electrode and the burner and between
10.3.8 Electrode distances
Fig.70 Electrode distance
18.0 ±
4.5 0.5±
Check the entire line of flue gas pipes, in particular the tightness of
the flue gas evacuation and combustion air intake connections.
10.3.6 Cleaning the siphon
Check that the boiler pump venting valve is working. In the event of a
leak replace the valve.
10 Maintenance
