INSTALLER Section (en)
7219620.01 (1-04/15)
11.1 CONNECTING THE ROOM THERMOSTAT
The connections in terminal block M1 are high voltage (230 V). Before making connections, make sure the appliance is
disconnected from the power supply. Respect polarity L (LIVE) - N (NEUTRAL).

 
 access the terminal block M1
 remove the jumper from the ends of contacts 1-2
 
11.2 ACCESSORIES NOT INCLUDED IN THE SUPPLY
11.2.1 EXTERNAL SENSOR
4-5)

SETTING THE "Kt" CLIMATE CURVE
When the external sensor is connected to the boiler, the
      
according to the set Kt
pressing
as indicated in the chart in annex SECTION
E for selecting the most appropriate one (00 to 90).
KEY TO CHART - “SECTION” E
 Outside temp
11.2.2 EXTERNAL STORAGE BOILER
              
"SECTION" F9-10 on terminal block M2.


 .
IMPORTANT: set parameter P03 = 05 as described in section 14.
11.2.3 CONNECTING TO A ZONE SYSTEM

KEY TO ELECTRICAL CONNECTIONS (see diagram in annex "SECTION" G at the end of this manual).
Z Zone (1..n) EV Zone electrovalve
R  RT Room thermostat

ambient thermostats can be used to control the other zones.
SYSTEM CONNECTIONS
 
 Connect the Ambient Thermostat contact of the other zones to terminals 1-2 of terminal block M1 (CONNECTING THE
AMBIENT THERMOSTAT section).
Check that parameter P04=02. Set parameter P10 (SETTING PARAMETERS section).





